Product Description
Built for precision and power, this 2025 Doosan DX45E mini excavator delivers reliable performance across digging, grading, and demolition tasks. With a 4,653 kg working weight and Yanmar V2403-M-D1-E3B-BC-5 engine producing 30.2 kW at 2200 rpm, this 5-ton machine handles demanding jobsite conditions with ease. Currently located in Shaoxing, Zhejiang, it's ready for immediate deployment on your next project.
- Maximum digging depth of 3,300 mm and reach of 5,802 mm for versatile excavation work
- Bucket digging force of 35.8 kN and rod digging force of 25.7 kN tackle tough materials efficiently
- Compact dimensions (5,353 mm length × 1,960 mm width) enable access to confined work areas
- Water-cooled 4-cylinder engine with 3.3L displacement ensures consistent power delivery
- 58% climbing ability and 9 rpm rotation speed optimize productivity on sloped terrain
- 79.9L fuel tank and 99.1 l/min hydraulic flow support extended operation cycles
Engineered for contractors requiring dependable compact excavation capacity, this Doosan E45 combines maneuverability with substantial digging force for foundation work, trenching, and material handling applications.
| Specifications | Value |
|---|---|
| No. | 1015710 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 4653 |
| Country of origin | America |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar Yanmar V2403-M-D1-E3B-BC-5 |
| Rated power (kw/rpm) | 30.2/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 87.1 by 102.4 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.3 |
| Rotation speed (rpm) | 9 |
| Climbing ability (%) | 58 |
| Bucket digging force (kN) | 35.8 |
| Rod digging force (kN) | 25.7 |
| Travel speed (km/h) | 2.4/4.2 |
| Maximum flow of main pump (l/min) | 99.1 |
| Fuel Tank (L) | 79.9 |
| Hydraulic Tank (L) | 15.1 |
| Engine Oil changes (L) | 7.1 |
| Coolant (L) | 8.3 |
| Hydraulic System (L) | 54.9 |
| Total transport length (mm) | 5353 |
| Total transport width (mm) | 1960 |
| Total transport height (mm) | 2532 |
| Full cab height (mm) | 2532 |
| Counterweight ground clearance (mm) | 640 |
| Minimum turning radius of front working device (mm) | 2491 |
| Track gauge (mm) | 1560 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 1960 |
| Track ground length (mm) | 1998 |
| Maximum digging radius (mm) | 5802 |
| Maximum digging depth (mm) | 3300 |
| Maximum excavation height (mm) | 5345 |
| Maximum unloading height (mm) | 3697 |
| Maximum vertical digging depth (mm) | 2815 |
| Bulldozer lift or depth (mm) | 384/465 |
| Dodging plate width × height (mm) | 1960 x 446 |
| Maximum excavation radius of stop surface (mm) | 5670 |
| Boom turning Angle (left/right °) | 70/55 |
