2010 Hitachi 50

1/7
Buy Hitachi 50 Used Excavator / 1
Buy Hitachi 50 Used Excavator / 2
Buy Hitachi 50 Used Excavator / 3
Buy Hitachi 50 Used Excavator / 4
Buy Hitachi 50 Used Excavator / 5
Buy Hitachi 50 Used Excavator / 6
Buy Hitachi 50 Used Excavator / 7

Product Description

This used Hitachi 50 excavator, located in Hebei, China, represents a solid investment for contractors seeking reliable earthmoving equipment. The machine retains its original factory paint, indicating careful operation and proper storage throughout its service life. Performance has been thoroughly verified and requires no additional inspection, allowing for immediate deployment to your worksite.

Key features include:

  • Original factory paint finish demonstrating quality maintenance
  • Performance-verified and ready for operation
  • Competitively priced for the current market
  • Located in Hebei, China for convenient regional access
  • Hitachi engineering and build quality

This excavator is suitable for general construction, excavation, and material handling applications. Contact us today for detailed specifications, current pricing, and shipping arrangements to your location.

SpecificationsValue
No.1051742
Tonnage (tons)25
Working weight (kg)24600
Bucket capacity (m³)1.2 Rock Type
Boom length (mm)6.00(H type)
Rod length (mm)2.96(H type)
Country of originJapan
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeISUZU CC-6BG1T
Rated power (kw/rpm)125/2100
Cooling modewater-cooling
Cylinder diameter × stroke (mm)105 x 125
Number of cylinders (PCS)6
Displacement (L)6.494
Working form4 stroke, water cooled, direct injection, turbocharged, intercooled
Ground specific pressure (Kpa)54
Rotation speed (rpm)13.5
Climbing ability (%)70
Bucket digging force (kN)18000
Rod digging force (kN)125
Travel speed (km/h)3.6/5.5
Rotary hydraulic motor typeAxial piston motor
Type of walking hydraulic motorVariable axial piston motor ×2
Maximum flow of main pump (l/min)204 x 2
Traveling Hydraulic Circuit (Mpa)34.8
Rotary Hydraulic Circuit (Mpa)31.4
Main pump typeVariable axial piston pump ×2
Working Hydraulic Circuit (Mpa)34.3
Pilot Oil Circuit (MPa)3.9
Bucket cylinders - Number × diameter × stroke (mm)1-130x90
Bucket rod cylinders - Number × diameter × stroke (mm)1-140 x 105
Boom cylinders - Number × diameter × stroke (mm)2-125 x 85
Fuel Tank (L)380
Hydraulic Tank (L)148
Engine Oil changes (L)25
Coolant (L)23
Hydraulic System (L)303
Total transport length (mm)10140
Total transport width (mm)2990
Total transport height (mm)3100
Full cab height (mm)3020
Counterweight ground clearance (mm)1090
Minimum ground clearance (mm)460
Back end turning radius (mm)2940
Total track length (mm)4260
Track gauge (mm)2390
Track plate width (mm)600
Total track width (mm)2990
Track ground length (mm)3460
Maximum digging radius (mm)10270
Maximum digging depth (mm)6950
Maximum excavation height (mm)9630
Maximum unloading height (mm)6760
Maximum vertical digging depth (mm)6020
Bulldozer lift or depth (mm)There is no
Dodging plate width × height (mm)There is no
Boom turning Angle (left/right °)There is no
see more

Overview

No.1051742

Brand Name:

Hitachi

Model Number:

50

Year:

2010

Location:

Hebei China

Pub Date
