Product Description
Powered by the robust Isuzu A-4BG1 engine, delivering 56.7 kW at 2000 rpm, the 2016 Hitachi EX100-5 excavator is a testament to precision engineering. With a working weight of 10,704.8 kg and a bucket capacity ranging from 0.3 to 0.59 m³, this machine is designed for efficiency and durability. The hydraulic system, with a capacity of 134 liters, ensures smooth and powerful operation, making it ideal for a variety of construction tasks.
- Engine: Isuzu A-4BG1, 56.7 kW, 4.3 L displacement
- Hydraulic System: 134 L capacity
- Working Weight: 10,700 kg
- Maximum Digging Depth: 4,780 mm
- Travel Speed: 5.5 km/h
- Fuel Tank: 250 L
Located in 浙江绍兴, this excavator offers a ground specific pressure of 37.2 Kpa, ensuring stability on various terrains. Its compact design, with a total transport width of 2,490 mm and height of 2,720 mm, allows for easy transportation and maneuverability on site. The backhoe bucket and versatile digging capabilities make the EX100-5 a reliable choice for demanding projects.
| Specifications | Value |
|---|---|
| No. | 1033007 |
| Tonnage (tons) | 10 |
| Working weight (kg) | 10704.8 |
| Bucket capacity (m³) | 0.3/0.19/0.59 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu A-4BG1 |
| Rated power (kw/rpm) | 56.7 |
| Displacement (L) | 4.3 |
| Ground specific pressure (Kpa) | 37.2 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 250 |
| Engine Oil changes (L) | 14.7 |
| Coolant (L) | 18.4 |
| Hydraulic System (L) | 134 |
| Total transport length (mm) | 7190 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2720 |
| Full cab height (mm) | 2720 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2620 |
| Maximum digging depth (mm) | 4780 |
| Maximum excavation height (mm) | 7930 |
| Maximum unloading height (mm) | 5530 |
| Maximum vertical digging depth (mm) | 4320 |
| Maximum excavation radius of stop surface (mm) | 7290 |
