Product Description
Maximize your equipment budget with this 2016 Hitachi EX120-5 excavator from Zhejiang, Hangzhou—a proven 12-ton workhorse delivering exceptional value against new machine pricing. Powered by a reliable Isuzu A-4BG1T engine producing 60.4kW, this joint-venture model combines robust performance with operational efficiency across diverse jobsite conditions.
Engineered for versatility, this machine offers impressive reach specifications: 7,770mm maximum excavation radius, 5,160mm digging depth, and 8,350mm excavation height. With three bucket configurations (0.3/0.19/0.66m³), you'll tackle everything from precision trenching to heavy loading applications. The 250L fuel tank and efficient hydraulic system (134L capacity) ensure extended operation between refills, reducing downtime and maximizing productivity.
Key investment advantages include:
- Compact transport dimensions (7,570mm length) for easy mobilization
- Low ground pressure (37.2kPa) protects sensitive terrain
- Proven Isuzu power plant with straightforward maintenance
- Immediate availability at a fraction of new equipment cost
Acquire professional-grade performance without the premium price tag—smart operators cho
| Specifications | Value |
|---|---|
| No. | 1021941 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 11793.4 |
| Bucket capacity (m³) | 0.3/0.19/0.66 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu A-4BG1T |
| Rated power (kw/rpm) | 60.4 |
| Displacement (L) | 4.3 |
| Ground specific pressure (Kpa) | 37.2 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 250 |
| Engine Oil changes (L) | 16.2 |
| Coolant (L) | 18.4 |
| Hydraulic System (L) | 134 |
| Total transport length (mm) | 7570 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2720 |
| Full cab height (mm) | 2720 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2880 |
| Maximum digging depth (mm) | 5160 |
| Maximum excavation height (mm) | 8350 |
| Maximum unloading height (mm) | 5940 |
| Maximum vertical digging depth (mm) | 4640 |
| Maximum excavation radius of stop surface (mm) | 7770 |
