Product Description
Ready to ship from Zhejiang, this 2016 Hitachi EX120-5 excavator eliminates factory wait times and gets your operation moving immediately. Powered by a reliable Isuzu A-4BG1T engine delivering 60.4 kW, this 12-ton machine combines proven performance with immediate availability. Skip the months-long procurement cycle—this unit is inspected, serviced, and available for fast deployment to your site.
Engineered for versatility across construction, demolition, and utility projects, the EX120-5 offers impressive working parameters in a compact footprint. Maximum digging depth reaches 5,160 mm with an excavation radius of 7,770 mm, while the 0.66 m³ bucket capacity handles substantial material volumes efficiently. Compact transport dimensions (7,570 mm length) simplify logistics, and the 250-liter fuel tank supports extended operation between refills.
Key Specifications:
- Operating weight: 11,793 kg with superior stability
- Isuzu 4.3L turbocharged engine for dependable power
- Maximum excavation height: 8,350 mm
- Ground clearance: 440 mm for varied terrain navigation
- Located in Zhejiang—available now for immediate purchase
Secure this proven perform
| Specifications | Value |
|---|---|
| No. | 1022197 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 11793.4 |
| Bucket capacity (m³) | 0.3/0.19/0.66 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu A-4BG1T |
| Rated power (kw/rpm) | 60.4 |
| Displacement (L) | 4.3 |
| Ground specific pressure (Kpa) | 37.2 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 250 |
| Engine Oil changes (L) | 16.2 |
| Coolant (L) | 18.4 |
| Hydraulic System (L) | 134 |
| Total transport length (mm) | 7570 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2720 |
| Full cab height (mm) | 2720 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2880 |
| Maximum digging depth (mm) | 5160 |
| Maximum excavation height (mm) | 8350 |
| Maximum unloading height (mm) | 5940 |
| Maximum vertical digging depth (mm) | 4640 |
| Maximum excavation radius of stop surface (mm) | 7770 |
