Built for endurance and engineered to deliver, this 2016 Hitachi EX120-5 excavator represents proven reliability in the 12-ton class. Powered by a robust Isuzu A-4BG1T engine delivering 60.4 kW, this machine combines Japanese engineering precision with field-tested durability. Currently located in Hangzhou, Zhejiang, it offers contractors a dependable solution for medium-duty excavation projects.
With an operating weight of 11,793 kg and a maximum digging depth of 5,160 mm, this workhorse handles demanding jobsite conditions with confidence. Key specifications include:
- Maximum excavation reach: 7,770 mm
- Maximum digging height: 8,350 mm
- Bucket capacity options: 0.3/0.19/0.66 m³
- Fuel capacity: 250L for extended operation
- Compact transport dimensions: 7,570 × 2,490 × 2,720 mm
Seven years of proven performance demonstrate the EX120-5's legendary build quality. This joint venture-manufactured excavator continues to meet the rigorous demands of professional contractors worldwide, offering exceptional value and long-term reliability for your equipment fleet.
| Specifications | Value |
|---|---|
| No. | 1022223 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 11793.4 |
| Bucket capacity (m³) | 0.3/0.19/0.66 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu A-4BG1T |
| Rated power (kw/rpm) | 60.4 |
| Displacement (L) | 4.3 |
| Ground specific pressure (Kpa) | 37.2 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 250 |
| Engine Oil changes (L) | 16.2 |
| Coolant (L) | 18.4 |
| Hydraulic System (L) | 134 |
| Total transport length (mm) | 7570 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2720 |
| Full cab height (mm) | 2720 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2880 |
| Maximum digging depth (mm) | 5160 |
| Maximum excavation height (mm) | 8350 |
| Maximum unloading height (mm) | 5940 |
| Maximum vertical digging depth (mm) | 4640 |
| Maximum excavation radius of stop surface (mm) | 7770 |
