Product Description
Built for immediate deployment on demanding worksites, this 2017 Hitachi EX130H-5 delivers consistent performance across excavation, grading, and material handling operations. Powered by a reliable Isuzu A-4BG1T engine producing 60.4 kW, this 13-ton excavator combines proven hydraulic technology with efficient fuel consumption from its 250-liter tank.
Operational capabilities include:
- Maximum digging depth of 5,360 mm for foundation and trenching work
- 8,140 mm excavation radius covering substantial working areas
- 0.66 m³ bucket capacity for high-volume material movement
- Compact 2,490 mm transport width enabling easy site-to-site mobility
- 134-liter hydraulic system ensuring responsive control
Currently located in Guizhou, this machine arrives work-ready with 12,201.6 kg operating weight providing excellent stability during digging and loading cycles. The 2,130 mm rear swing radius allows productive operation in confined spaces, while the 5.5 km/h travel speed maintains efficiency between work zones. Ready to tackle your next project without delay.
| Specifications | Value |
|---|---|
| No. | 1019134 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12201.6 |
| Bucket capacity (m³) | 0.3/0.19/0.66 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu A-4BG1T |
| Rated power (kw/rpm) | 60.4 |
| Displacement (L) | 4.3 |
| Ground specific pressure (Kpa) | 38.3 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 250 |
| Engine Oil changes (L) | 16.2 |
| Coolant (L) | 18.4 |
| Hydraulic System (L) | 134 |
| Total transport length (mm) | 7580 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2720 |
| Full cab height (mm) | 2720 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2880 |
| Maximum digging depth (mm) | 5360 |
| Maximum excavation height (mm) | 8550 |
| Maximum unloading height (mm) | 6140 |
| Maximum vertical digging depth (mm) | 5010 |
| Maximum excavation radius of stop surface (mm) | 8140 |
