Product Description
Available now from our Hunan facility, this 2017 Hitachi EX130H-5 eliminates factory wait times and delivers immediate productivity to your jobsite. Powered by a robust Isuzu A-4BG1T engine producing 60.4 kW, this 13-ton excavator combines proven reliability with the performance metrics your operations demand. Skip the lead times—this machine is ready for fast deployment across regional and international projects.
- Operating Weight: 12,201.6 kg with optimal 38.3 kPa ground pressure for diverse terrain
- Reach & Depth: 8,140 mm maximum excavation radius, 5,360 mm digging depth
- Bucket Options: 0.3/0.19/0.66 m³ configurations for versatile applications
- Power System: 4.3L displacement, 250L fuel capacity for extended runtime
- Transport Dimensions: 7,580 × 2,490 × 2,720 mm—optimized for standard logistics
- Location: Hunan—strategically positioned for rapid inland and export shipping
Secure this turnkey excavator today. Immediate availability means your project timeline stays on schedule without the typical procurement delays associated with new equipment orders.
| Specifications | Value |
|---|---|
| No. | 1042584 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12201.6 |
| Bucket capacity (m³) | 0.3/0.19/0.66 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu A-4BG1T |
| Rated power (kw/rpm) | 60.4 |
| Displacement (L) | 4.3 |
| Ground specific pressure (Kpa) | 38.3 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 250 |
| Engine Oil changes (L) | 16.2 |
| Coolant (L) | 18.4 |
| Hydraulic System (L) | 134 |
| Total transport length (mm) | 7580 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2720 |
| Full cab height (mm) | 2720 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2880 |
| Maximum digging depth (mm) | 5360 |
| Maximum excavation height (mm) | 8550 |
| Maximum unloading height (mm) | 6140 |
| Maximum vertical digging depth (mm) | 5010 |
| Maximum excavation radius of stop surface (mm) | 8140 |
