Product Description
With a working weight of 12,201.6 kg and a powerful Isuzu A-4BG1T engine, this 2023 Hitachi EX130H-5 excavator offers robust performance for your construction needs. Located in Anhui, China, this machine is a smart investment, providing high efficiency at a fraction of the cost of new equipment. Equipped with a backhoe bucket, it delivers versatile digging capabilities, including a maximum digging depth of 5,360 mm and a maximum excavation height of 8,550 mm. The traditional power system ensures reliable operation, while the 250-liter fuel tank supports extended work periods. Choose this used Hitachi excavator for a cost-effective solution that doesn't compromise on quality or performance.
- Working weight: 12,201.6 kg
- Engine: Isuzu A-4BG1T, 60.4 kW
- Maximum digging depth: 5,360 mm
- Maximum excavation height: 8,550 mm
- Fuel tank capacity: 250 L
| Specifications | Value |
|---|---|
| No. | 1056952 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12201.6 |
| Bucket capacity (m³) | 0.3/0.19/0.66 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu A-4BG1T |
| Rated power (kw/rpm) | 60.4 |
| Displacement (L) | 4.3 |
| Ground specific pressure (Kpa) | 38.3 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 250 |
| Engine Oil changes (L) | 16.2 |
| Coolant (L) | 18.4 |
| Hydraulic System (L) | 134 |
| Total transport length (mm) | 7580 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2720 |
| Full cab height (mm) | 2720 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2880 |
| Maximum digging depth (mm) | 5360 |
| Maximum excavation height (mm) | 8550 |
| Maximum unloading height (mm) | 6140 |
| Maximum vertical digging depth (mm) | 5010 |
| Maximum excavation radius of stop surface (mm) | 8140 |
