Product Description
Built for high-output earthmoving and excavation work, this 2014 Hitachi EX200-5 delivers 98.4 kW of ISUZU turbocharged power across demanding jobsites. Operating at 20 tons with an 18,824 kg working weight, this machine handles foundation digging, trench work, and material loading with proven reliability. The 0.8 m³ backhoe bucket, paired with a 5,680 mm boom and 2,910 mm arm, provides optimal reach and breakout force for grading, demolition prep, and utility installation.
- Engine: ISUZU A-6BG1T, 6-cylinder water-cooled diesel, 6.5L displacement, 1950 rpm rated speed
- Hydraulics: 200L tank capacity for sustained performance under load
- Mobility: 3.4/5.5 km/h travel speeds, 70% (35°) grading ability, 2,750 mm rear swing radius
- Undercarriage: 600 mm track plates, 3,770 mm ground contact length, 42.1 kPa ground pressure for stable operation
- Fuel Capacity: 310L tank supports extended shifts without refueling downtime
- Transport Dimensions: 9,620 mm length × 2,800 mm width × 3,090 mm height
Currently located in Shaoxing, Zhejiang. Site-ready condition for
| Specifications | Value |
|---|---|
| No. | 1028904 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 18824.1 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU A-6BG1T |
| Rated power (kw/rpm) | 98.4/1950 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.5 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42.1 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 3.4/5.5 |
| Fuel Tank (L) | 310 |
| Hydraulic Tank (L) | 200 |
| Engine Oil changes (L) | 25 |
| Coolant (L) | 23 |
| Total transport length (mm) | 9620 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3090 |
| Full cab height (mm) | 2870 |
| Counterweight ground clearance (mm) | 1030 |
| Minimum ground clearance (mm) | 450 |
| Back end turning radius (mm) | 2750 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3770 |
