Product Description
Built for operators who demand precision and control, this 2016 Hitachi EX200-5 excavator delivers reliable performance across demanding job sites. Manufactured in Japan with proven joint venture quality, this 20-ton machine combines an ISUZU A-6BG1T engine producing 98.4kW at 1950rpm with water-cooled efficiency and turbocharging technology. Operators benefit from exceptional visibility through the full cab design, positioned 2870mm high for commanding site awareness.
Handling characteristics include a compact 2750mm rear turning radius and responsive hydraulics managing a 0.8m³ backhoe bucket through a 5680mm boom and 2910mm arm configuration. Stability remains uncompromised with an 18,824kg working weight distributed across 600mm track plates, achieving 42.1kPa ground pressure. Twin travel speeds of 3.4/5.5 km/h provide flexibility between precision positioning and efficient relocation.
- ISUZU 6-cylinder turbocharged engine: 6.5L displacement
- 70% gradeability (35° slope capability)
- 310L fuel capacity for extended operation
- 3770mm track ground contact for enhanced stability
- Currently located in Hunan, China
| Specifications | Value |
|---|---|
| No. | 1024665 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 18824.1 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU A-6BG1T |
| Rated power (kw/rpm) | 98.4/1950 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.5 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42.1 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 3.4/5.5 |
| Fuel Tank (L) | 310 |
| Hydraulic Tank (L) | 200 |
| Engine Oil changes (L) | 25 |
| Coolant (L) | 23 |
| Total transport length (mm) | 9620 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3090 |
| Full cab height (mm) | 2870 |
| Counterweight ground clearance (mm) | 1030 |
| Minimum ground clearance (mm) | 450 |
| Back end turning radius (mm) | 2750 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3770 |
