Product Description
Built for operators who demand precision and reliability, this 2019 Hitachi EX200-5 delivers 20-ton performance with exceptional visibility and control. Powered by an ISUZU A-6BG1T engine generating 98.4 kW at 1950 rpm, this Japan-engineered excavator combines proven water-cooled technology with responsive hydraulics. The spacious cab sits 2,870 mm high, offering commanding sightlines across the 5,680 mm boom and 2,910 mm arm for confident backhoe operations.
- Operating weight: 18,824 kg with 0.8 m³ bucket capacity
- Superior stability: 42.1 kPa ground pressure across 3,770 mm track length
- Turbocharged 6-cylinder engine: 6.5L displacement for consistent power delivery
- Dual travel speeds: 3.4/5.5 km/h for precise positioning or efficient repositioning
- Generous fluid capacities: 310L fuel, 200L hydraulic oil for extended shifts
- Compact 2,750 mm rear turning radius for confined jobsite maneuverability
- Currently located in Hefei, Anhui—ready for immediate deployment
Designed with operator comfort and productivity in mind, this EX200-5 represents Hitachi's commitment to durable, field-proven excavation equipment.
| Specifications | Value |
|---|---|
| No. | 1030002 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 18824.1 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU A-6BG1T |
| Rated power (kw/rpm) | 98.4/1950 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.5 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42.1 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 3.4/5.5 |
| Fuel Tank (L) | 310 |
| Hydraulic Tank (L) | 200 |
| Engine Oil changes (L) | 25 |
| Coolant (L) | 23 |
| Total transport length (mm) | 9620 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3090 |
| Full cab height (mm) | 2870 |
| Counterweight ground clearance (mm) | 1030 |
| Minimum ground clearance (mm) | 450 |
| Back end turning radius (mm) | 2750 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3770 |
