Product Description
Expand your operational capacity with this 2016 Hitachi EX350H-5 excavator, currently located in Luzhou, Sichuan. Engineered for demanding job sites, this 35-ton workhorse delivers reliable performance through its Isuzu B-6SD1T engine, rated at 169 kW at 1900 rpm. With a 1.4 m³ backhoe bucket and maximum digging depth of 7,380 mm, this machine handles diverse excavation tasks with proven efficiency.
- Operating weight: 32,613 kg with low ground pressure (66 kPa)
- Maximum excavation radius: 11,100 mm for extended reach capability
- 560-liter fuel tank supports extended operation cycles
- Maximum digging height: 10,230 mm for versatile applications
- Compact transport dimensions: 10,950 × 3,190 × 3,230 mm
- Joint venture/import quality construction standards
Perfect as a backup unit or fleet addition, this EX350H-5 minimizes downtime risks while maintaining consistent productivity across multiple projects. Ready for immediate deployment in your construction or earthmoving operations.
| Specifications | Value |
|---|---|
| No. | 1050688 |
| Tonnage (tons) | 35 |
| Working weight (kg) | 32613.3 |
| Bucket capacity (m³) | 1.4 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu B-6SD1T |
| Rated power (kw/rpm) | 169/1900 |
| Ground specific pressure (Kpa) | 66 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 560 |
| Total transport length (mm) | 10950 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3230 |
| Full cab height (mm) | 3110 |
| Counterweight ground clearance (mm) | 1140 |
| Minimum ground clearance (mm) | 500 |
| Back end turning radius (mm) | 3290 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3730 |
| Maximum digging depth (mm) | 7380 |
| Maximum excavation height (mm) | 10230 |
| Maximum unloading height (mm) | 7130 |
| Maximum vertical digging depth (mm) | 6480 |
| Maximum excavation radius of stop surface (mm) | 11100 |
