Product Description
Built to endure the most demanding jobsites, this 2020 Hitachi EX350H-5 stands as a proven workhorse in the 35-ton excavator class. Powered by a robust Isuzu B-6SD1T engine delivering 169 kW at 1,900 RPM, it combines raw digging force with the long-term reliability Hitachi engineering is known for worldwide. Six years of operational history on this machine speak directly to its structural integrity and build quality — this unit has earned its reputation on the ground.
Sourced from Shandong, China, and available for global export, this backhoe excavator is ready to get back to work on your site without hesitation.
- Working Weight: 32,613 kg | Bucket Capacity: 1.4 m³
- Engine: Isuzu B-6SD1T | Rated Power: 169 kW / 1,900 RPM
- Maximum Digging Depth: 7,380 mm | Max Excavation Radius: 11,100 mm
- Maximum Excavation Height: 10,230 mm | Max Unloading Height: 7,130 mm
- Fuel Tank Capacity: 560 L | Travel Speed: 5.5 km/h
- Track Plate Width: 600 mm | Ground Pressure: 66 kPa
- Transport Dimensions: 10,950 mm (L) × 3,190 mm (W) × 3,230 mm (H)
| Specifications | Value |
|---|---|
| No. | 1080550 |
| Tonnage (tons) | 35 |
| Working weight (kg) | 32613.3 |
| Bucket capacity (m³) | 1.4 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu B-6SD1T |
| Rated power (kw/rpm) | 169/1900 |
| Ground specific pressure (Kpa) | 66 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 560 |
| Total transport length (mm) | 10950 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3230 |
| Full cab height (mm) | 3110 |
| Counterweight ground clearance (mm) | 1140 |
| Minimum ground clearance (mm) | 500 |
| Back end turning radius (mm) | 3290 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3730 |
| Maximum digging depth (mm) | 7380 |
| Maximum excavation height (mm) | 10230 |
| Maximum unloading height (mm) | 7130 |
| Maximum vertical digging depth (mm) | 6480 |
| Maximum excavation radius of stop surface (mm) | 11100 |
