Product Description
This 2014 Hitachi EX60-5 mini excavator represents a reliable solution for contractors seeking proven Japanese engineering at competitive value. Currently located in Hunan, China, this machine offers the compact versatility and durability that have made the EX60 series a trusted choice in construction, landscaping, and utility work worldwide.
The Hitachi EX60-5 is designed for efficient operation in confined spaces while delivering consistent performance across various applications. With over a decade of the EX series heritage, this model combines mechanical reliability with straightforward maintenance accessibility.
Key features include:
- Compact dimensions for urban job sites and restricted access areas
- Fuel-efficient operation for reduced running costs
- Robust undercarriage designed for extended service life
- Intuitive controls for operator productivity
Available for immediate inspection in Hunan Province. Competitive pricing reflects current market conditions for equipment of this vintage and specification.
| Specifications | Value |
|---|---|
| No. | 1083806 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 6300 |
| Boom length (mm) | 3720 |
| Rod length (mm) | 1620 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Nissan A-BD30 |
| Rated power (kw/rpm) | 40.3/2200 |
| Cooling mode | water-cooling |
| Displacement (L) | 3 |
| Ground specific pressure (Kpa) | 29.4 |
| Rotation speed (rpm) | 14.5 |
| Travel speed (km/h) | 4.8 |
| Maximum flow of main pump (l/min) | 158.4 |
| Fuel Tank (L) | 35.7 |
| Engine Oil changes (L) | 12.5 |
| Coolant (L) | 10 |
| Hydraulic System (L) | 90 |
| Total transport length (mm) | 6080 |
| Total transport width (mm) | 2200 |
| Total transport height (mm) | 2570 |
| Full cab height (mm) | 2570 |
| Counterweight ground clearance (mm) | 760 |
| Minimum ground clearance (mm) | 360 |
| Back end turning radius (mm) | 1750 |
| Track gauge (mm) | 1750 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2200 |
| Track ground length (mm) | 2140 |
| Maximum digging depth (mm) | 4150 |
| Maximum excavation height (mm) | 7150 |
| Maximum unloading height (mm) | 5070 |
| Maximum vertical digging depth (mm) | 3520 |
| Maximum excavation radius of stop surface (mm) | 6160 |
