Product Description
Engineered with precision by Hitachi's joint venture manufacturing division, the ZAXIS200 delivers robust 20-ton class performance through proven hydraulic architecture. At its core, a rated power output of 103 kW at 1900 rpm drives consistent productivity across demanding excavation tasks, while maintaining ground-specific pressure at just 49 kPa for superior site versatility and reduced ground disturbance.
Technical specifications demonstrate the model's operational reach and depth capabilities:
- Maximum digging radius: 9,910 mm for extended work envelope
- Maximum digging depth: 6,480 mm with 2,910 mm rod configuration
- Maximum excavation height: 9,780 mm for elevated loading operations
- Bucket capacity: 0.8 m³ optimized for balanced cycle times
- Operating weight: 21,700 kg with 600 mm track plates
Currently located in Suqian, Jiangsu Province, this backhoe-configured excavator represents Hitachi's commitment to hydraulic efficiency and structural durability. Maximum vertical digging depth of 5,870 mm and unloading height of 6,970 mm provide operational flexibility for infrastructure, utility, and general earthmoving applications requiring reliable mid-size excava
| Specifications | Value |
|---|---|
| No. | 1013623 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21700 |
| Bucket capacity (m³) | 0.8 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 103/1900 |
| Ground specific pressure (Kpa) | 49 |
| Maximum digging radius (mm) | 9910 |
| Maximum digging depth (mm) | 6480 |
| Maximum excavation height (mm) | 9780 |
| Maximum unloading height (mm) | 6970 |
| Maximum vertical digging depth (mm) | 5870 |
| Track plate width (mm) | 600 |
