Product Description
Engineered for demanding excavation operations, this ZAXIS200 delivers robust performance through its 103kW rated power output at 1900 rpm, paired with precision hydraulics that maximize efficiency across all working ranges. With a 20-ton operating class and 21,700 kg working weight, this machine demonstrates Hitachi's commitment to balanced design and structural integrity.
Technical specifications underscore its versatility in济南's construction landscape:
- Maximum digging reach of 9,910 mm enables extended working envelope
- Digging depth capacity of 6,480 mm handles deep foundation work
- 0.8 m³ backhoe bucket optimizes material handling productivity
- 2,910 mm rod length provides operational flexibility
- 600 mm track plate width with 49 kPa ground pressure ensures stability without excessive surface impact
Built to joint venture/import manufacturing standards, the ZAXIS200 represents proven engineering from a globally recognized manufacturer. Maximum unloading height of 6,970 mm facilitates efficient truck loading, while the 9,780 mm excavation height extends vertical reach for challenging applications. This model combines traditional power reliability with the techn
| Specifications | Value |
|---|---|
| No. | 997289 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21700 |
| Bucket capacity (m³) | 0.8 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 103/1900 |
| Ground specific pressure (Kpa) | 49 |
| Maximum digging radius (mm) | 9910 |
| Maximum digging depth (mm) | 6480 |
| Maximum excavation height (mm) | 9780 |
| Maximum unloading height (mm) | 6970 |
| Maximum vertical digging depth (mm) | 5870 |
| Track plate width (mm) | 600 |
