Product Description
Engineered for precision and all-day productivity, this 2021 Hitachi ZH200-5A hydraulic excavator combines hybrid power efficiency with proven operator-centric design. Operating at 20 tons with a 113 kW Isuzu engine, this machine delivers consistent performance across demanding job sites in Hefei, Anhui and beyond. Hybrid technology reduces fuel consumption while maintaining robust digging forces of 158 kN (bucket) and 114 kN (arm), ensuring reliable material handling in varied ground conditions.
- Superior Visibility: Spacious cab design with 2950mm height provides excellent sightlines to the 9920mm maximum digging radius
- Stable Performance: 2800mm track width and 46 kPa ground pressure ensure balanced operation on soft terrain
- Responsive Controls: 11.5 rpm rotation speed and precise hydraulics enable smooth, fatigue-reducing operation
- Extended Range: 400L fuel tank supports longer shifts with fewer refueling interruptions
- Proven Reliability: Joint venture manufacturing standards with Isuzu GI-4HK1XKSA-03 engine platform
Currently located in Hefei, this ZH200-5A represents a cost-effect
| Specifications | Value |
|---|---|
| No. | 1026726 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.91 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Hybrid power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu GI-4HK1XKSA-03 |
| Rated power (kw/rpm) | 113/2000 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 5.193 |
| Working form | 4 stroke, water cooled, electrically controlled direct injection |
| Ground specific pressure (Kpa) | 46 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 158 |
| Rod digging force (kN) | 114 |
| Travel speed (km/h) | 3.5-5.5 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 200 |
| Engine Oil changes (L) | 23 |
| Total transport length (mm) | 9660 |
| Total transport width (mm) | 2860 |
| Total transport height (mm) | 3010 |
| Full cab height (mm) | 2950 |
| Counterweight ground clearance (mm) | 1030 |
| Minimum ground clearance (mm) | 450 |
| Minimum turning radius of front working device (mm) | 3180 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4170 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Maximum digging radius (mm) | 9920 |
| Maximum digging depth (mm) | 6670 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 7180 |
| Maximum vertical digging depth (mm) | 5990 |
| Maximum excavation radius of stop surface (mm) | 9750 |
