Product Description
Engineered with hybrid power technology, this 2021 Hitachi ZH200-5A delivers exceptional fuel efficiency without compromising performance. At its core, the Isuzu GI-4HK1XKSA-03 engine generates 113 kW at 2000 rpm through a 5.193L displacement, providing robust power for demanding excavation tasks. Operating at 20 tons with a working weight of 20,900 kg, this joint venture-manufactured machine combines Japanese engineering precision with intelligent energy management.
Hydraulic capabilities define this model's technical superiority. Bucket digging force reaches 158 kN while rod digging force delivers 114 kN, supported by a maximum digging radius of 9,920 mm and depth capacity of 6,670 mm. The 0.91 m³ backhoe bucket pairs with a 5,680 mm boom and 2,910 mm rod for versatile reach and precision. With a 70% climbing ability, 11.5 rpm rotation speed, and ground pressure of just 46 kPa, this excavator maintains stability across challenging terrain.
Currently located in Guizhou, this ZH200-5A represents advanced hybrid technology in the 20-ton class, offering reduced operational costs and proven reliability for contractors seeking technical excellence.
| Specifications | Value |
|---|---|
| No. | 1027666 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.91 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Hybrid power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu GI-4HK1XKSA-03 |
| Rated power (kw/rpm) | 113/2000 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 5.193 |
| Working form | 4 stroke, water cooled, electrically controlled direct injection |
| Ground specific pressure (Kpa) | 46 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 158 |
| Rod digging force (kN) | 114 |
| Travel speed (km/h) | 3.5-5.5 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 200 |
| Engine Oil changes (L) | 23 |
| Total transport length (mm) | 9660 |
| Total transport width (mm) | 2860 |
| Total transport height (mm) | 3010 |
| Full cab height (mm) | 2950 |
| Counterweight ground clearance (mm) | 1030 |
| Minimum ground clearance (mm) | 450 |
| Minimum turning radius of front working device (mm) | 3180 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4170 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Maximum digging radius (mm) | 9920 |
| Maximum digging depth (mm) | 6670 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 7180 |
| Maximum vertical digging depth (mm) | 5990 |
| Maximum excavation radius of stop surface (mm) | 9750 |
