Product Description
Engineered for precision and control, this 2022 Hitachi ZH200-5A hybrid excavator delivers exceptional operator confidence across demanding jobsites. Powered by an Isuzu 4-cylinder engine producing 113 kW at 2000 rpm, the hybrid system optimizes fuel efficiency while maintaining robust digging force—158 kN bucket force and 114 kN arm force ensure consistent performance in tough materials.
Operator-focused design features include:
- Spacious cab with enhanced visibility, positioned 2,950 mm high for superior sightlines to the working area
- Smooth 11.5 rpm rotation speed enabling precise positioning around obstacles
- Stable 2,200 mm track gauge and 600 mm wide track plates for confident operation on uneven terrain
- Responsive hydraulic controls managing a 9,920 mm maximum digging reach and 6,670 mm digging depth
- Excellent stability from 20,900 kg working weight and optimized 46 kPa ground pressure
Currently located in Hangzhou, Zhejiang, this 20-ton class machine combines proven Japanese engineering with hybrid efficiency. The 400L fuel tank and 200L hydraulic reservoir support extended operation between refills, minimizing downtime on remote sites.
| Specifications | Value |
|---|---|
| No. | 1029266 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.91 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Hybrid power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu GI-4HK1XKSA-03 |
| Rated power (kw/rpm) | 113/2000 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 5.193 |
| Working form | 4 stroke, water cooled, electrically controlled direct injection |
| Ground specific pressure (Kpa) | 46 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 158 |
| Rod digging force (kN) | 114 |
| Travel speed (km/h) | 3.5-5.5 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 200 |
| Engine Oil changes (L) | 23 |
| Total transport length (mm) | 9660 |
| Total transport width (mm) | 2860 |
| Total transport height (mm) | 3010 |
| Full cab height (mm) | 2950 |
| Counterweight ground clearance (mm) | 1030 |
| Minimum ground clearance (mm) | 450 |
| Minimum turning radius of front working device (mm) | 3180 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4170 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Maximum digging radius (mm) | 9920 |
| Maximum digging depth (mm) | 6670 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 7180 |
| Maximum vertical digging depth (mm) | 5990 |
| Maximum excavation radius of stop surface (mm) | 9750 |
