Product Description
Engineered for precision and all-day productivity, this 2022 Hitachi ZH200-5A hybrid excavator delivers exceptional operator comfort and control across demanding jobsites. Powered by an Isuzu GI-4HK1XKSA-03 engine generating 113 kW at 2000 rpm, the hybrid system optimizes fuel efficiency while maintaining robust performance for a 20-ton machine with 20,900 kg working weight.
Operators benefit from superior visibility and responsive handling thanks to the spacious cab design and balanced 46 kPa ground pressure distribution. The hydraulic system provides confident digging force—158 kN bucket force and 114 kN arm force—ensuring smooth, controlled movements whether trenching to 6,670 mm depth or reaching 9,920 mm radius. Stability remains exceptional even on slopes up to 70% grade, while the 11.5 rpm rotation speed enables efficient load cycles.
- 0.91 m³ bucket capacity with backhoe configuration
- 400L fuel tank for extended operation between refills
- Compact 2,890 mm rear swing radius for confined spaces
- Currently located in Hangzhou, Zhejiang—ready for global export
| Specifications | Value |
|---|---|
| No. | 1032818 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.91 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Hybrid power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu GI-4HK1XKSA-03 |
| Rated power (kw/rpm) | 113/2000 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 5.193 |
| Working form | 4 stroke, water cooled, electrically controlled direct injection |
| Ground specific pressure (Kpa) | 46 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 158 |
| Rod digging force (kN) | 114 |
| Travel speed (km/h) | 3.5-5.5 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 200 |
| Engine Oil changes (L) | 23 |
| Total transport length (mm) | 9660 |
| Total transport width (mm) | 2860 |
| Total transport height (mm) | 3010 |
| Full cab height (mm) | 2950 |
| Counterweight ground clearance (mm) | 1030 |
| Minimum ground clearance (mm) | 450 |
| Minimum turning radius of front working device (mm) | 3180 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4170 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Maximum digging radius (mm) | 9920 |
| Maximum digging depth (mm) | 6670 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 7180 |
| Maximum vertical digging depth (mm) | 5990 |
| Maximum excavation radius of stop surface (mm) | 9750 |
