Product Description
Built for relentless performance, this 2011 Hitachi ZW330 wheel loader stands as a proven workhorse in heavy-duty material handling operations. Powered by a robust Cummins QSM11 engine delivering 242 kW at 1800 rpm, this machine combines exceptional reliability with formidable digging force of 226 kN. Operating weight ranges from 25,725 to 26,075 kg, providing the stability needed for demanding applications.
- Engine: Cummins QSM11, 10.82L displacement, 4-stroke water-cooled direct injection
- Bucket Capacity: 3.9-5.0 m³ for versatile loading tasks
- Performance: 6.4-second lift cycle, 3,255 mm unloading height at 45° angle
- Mobility: Four-speed transmission with maximum travel speed of 35.5 km/h
- Tire Specification: 26.5-25-20PR (L3) for superior traction
- Fuel Capacity: 424L tank for extended operation
- Location: Jinan, Shandong, China
With over a decade of operational heritage, this ZW330 exemplifies Hitachi's engineering excellence and durability. A tested, field-proven solution ready for your toughest loading challenges.
| Specifications | Value |
|---|---|
| No. | 1014965 |
| Engine type | Cummins QSM11 |
| Rated power (kw/rpm) | 242/1800 |
| Cylinder diameter × stroke (mm) | 125 x 147 |
| Working form | 4 stroke, water cooled, direct injection |
| Exhaust volume (L) | 10.82 |
| Bucket capacity (m³) | 3.9-5.0 |
| Rated load (tons) | |
| Digging force (lifting force) (kN) | 226 |
| Machine operating weight (kg) | 25725-26075 |
| Unloading height - Unloading Angle 45°(mm) | 3255 |
| Driving form | |
| Tyre specification | 26.5-25-20PR(L3) |
| Fuel Tank (L) | 424 |
| Hydraulic Tank (L) | 162 |
| Coolant (L) | 72 |
| Engine Oil (L) | 37 |
| Wheelbase (mm) | 3550 |
| Wheel base (mm) | 2300 |
| Minimum ground clearance (mm) | 460 |
| Machine length (mm) | 9050 |
| Machine height (mm) | 6160 |
| Minimum turning radius of outer wheel center line | 6455 |
| Steering form | |
| Boom cylinder diameter × stroke (mm×mm) | |
| Bucket cylinder diameter × stroke (mm×mm) | |
| Lift (s) | 6.4 |
| Unloading (s) | 3.3 |
| Lower empty bucket (s) | 1.4 |
| Ternary sum (s) | 11.1 |
| Speed 1 gear (km/h) | 7.2/7.8 |
| Speed 2 (km/h) | 12.4/13.5 |
| Speed 3 (km/h) | 21.6/23.2 |
| Speed 4 (km/h) | 34.4/35.5 |
| Service brake |
