Product Description
Available now in Guizhou, this 2012 Hitachi ZW330 wheel loader delivers immediate operational capability without factory lead times. Powered by a robust Cummins QSM11 engine generating 242 kW at 1800 rpm, this machine combines proven reliability with impressive performance metrics for demanding material handling applications.
Operating at 25,725-26,075 kg, the ZW330 offers exceptional productivity with bucket capacities ranging from 3.9 to 5.0 m³ and a digging force of 226 kN. Four-speed transmission provides versatility from 7.2 km/h in first gear to 35.5 km/h in fourth, enabling rapid site repositioning and efficient cycle times. The ternary sum of just 11.1 seconds ensures maximum material movement per hour.
- Cummins QSM11 engine: 242 kW, 10.82L displacement
- Bucket capacity: 3.9-5.0 m³ with 226 kN digging force
- Four-speed transmission: up to 35.5 km/h maximum speed
- 26.5-25-20PR tires for Guizhou terrain conditions
- Fast deployment—ready for immediate site integration
Skip extended procurement cycles. This unit is positioned in Guizhou for rapid mobilization to your operation.
| Specifications | Value |
|---|---|
| No. | 999978 |
| Engine type | Cummins QSM11 |
| Rated power (kw/rpm) | 242/1800 |
| Cylinder diameter × stroke (mm) | 125 x 147 |
| Working form | 4 stroke, water cooled, direct injection |
| Exhaust volume (L) | 10.82 |
| Bucket capacity (m³) | 3.9-5.0 |
| Rated load (tons) | |
| Digging force (lifting force) (kN) | 226 |
| Machine operating weight (kg) | 25725-26075 |
| Unloading height - Unloading Angle 45°(mm) | 3255 |
| Driving form | |
| Tyre specification | 26.5-25-20PR(L3) |
| Fuel Tank (L) | 424 |
| Hydraulic Tank (L) | 162 |
| Coolant (L) | 72 |
| Engine Oil (L) | 37 |
| Wheelbase (mm) | 3550 |
| Wheel base (mm) | 2300 |
| Minimum ground clearance (mm) | 460 |
| Machine length (mm) | 9050 |
| Machine height (mm) | 6160 |
| Minimum turning radius of outer wheel center line | 6455 |
| Steering form | |
| Boom cylinder diameter × stroke (mm×mm) | |
| Bucket cylinder diameter × stroke (mm×mm) | |
| Lift (s) | 6.4 |
| Unloading (s) | 3.3 |
| Lower empty bucket (s) | 1.4 |
| Ternary sum (s) | 11.1 |
| Speed 1 gear (km/h) | 7.2/7.8 |
| Speed 2 (km/h) | 12.4/13.5 |
| Speed 3 (km/h) | 21.6/23.2 |
| Speed 4 (km/h) | 34.4/35.5 |
| Service brake |
