Product Description
Built for high-capacity loading and hauling operations, this 2018 Hitachi ZW330 wheel loader delivers 242 kW of Cummins QSM11 power to tackle demanding earthmoving projects. With a bucket capacity ranging from 3.9 to 5.0 m³ and 226 kN of digging force, this machine handles heavy material with efficiency. Operating weight sits between 25,725-26,075 kg, providing the stability needed for continuous production cycles.
Performance specs include a 6.4-second lift time and 3.3-second unloading cycle, maximizing productivity on loading docks and construction sites. Four-speed transmission reaches up to 35.5 km/h for rapid repositioning between work zones. Equipped with 26.5-25-20PR L3 tires and 460 mm ground clearance, this loader navigates rough terrain while maintaining traction. The 424-liter fuel tank supports extended shifts without frequent refueling stops.
Currently located in Shanghai and ready for immediate deployment. Ideal for quarry operations, demolition sites, stockpile management, and heavy civil construction where robust loading capacity matters.
- Cummins QSM11 engine: 242 kW @ 1800 rpm
- Bucket capacity: 3.9-5.0 m³
- Operating weight: 25,725-26,075 kg
- Digging force: 226 k
| Specifications | Value |
|---|---|
| No. | 1016000 |
| Engine type | Cummins QSM11 |
| Rated power (kw/rpm) | 242/1800 |
| Cylinder diameter × stroke (mm) | 125 x 147 |
| Working form | 4 stroke, water cooled, direct injection |
| Exhaust volume (L) | 10.82 |
| Bucket capacity (m³) | 3.9-5.0 |
| Rated load (tons) | |
| Digging force (lifting force) (kN) | 226 |
| Machine operating weight (kg) | 25725-26075 |
| Unloading height - Unloading Angle 45°(mm) | 3255 |
| Driving form | |
| Tyre specification | 26.5-25-20PR(L3) |
| Fuel Tank (L) | 424 |
| Hydraulic Tank (L) | 162 |
| Coolant (L) | 72 |
| Engine Oil (L) | 37 |
| Wheelbase (mm) | 3550 |
| Wheel base (mm) | 2300 |
| Minimum ground clearance (mm) | 460 |
| Machine length (mm) | 9050 |
| Machine height (mm) | 6160 |
| Minimum turning radius of outer wheel center line | 6455 |
| Steering form | |
| Boom cylinder diameter × stroke (mm×mm) | |
| Bucket cylinder diameter × stroke (mm×mm) | |
| Lift (s) | 6.4 |
| Unloading (s) | 3.3 |
| Lower empty bucket (s) | 1.4 |
| Ternary sum (s) | 11.1 |
| Speed 1 gear (km/h) | 7.2/7.8 |
| Speed 2 (km/h) | 12.4/13.5 |
| Speed 3 (km/h) | 21.6/23.2 |
| Speed 4 (km/h) | 34.4/35.5 |
| Service brake |
