Product Description
Maximize your equipment budget with this 2012 Hitachi ZX120 excavator from Jiangsu—a proven workhorse delivering professional-grade performance at a fraction of new equipment costs. Operating at 12 tons with a robust 12,200 kg working weight, this machine combines the reliability of ISUZU CC-4BG1TC power (66 kw at 2150 rpm) with impressive operational capabilities that rival current models.
Built for demanding jobsites, this joint venture-manufactured unit features a 0.52 m³ bucket capacity, 8,270 mm maximum digging radius, and 5,570 mm digging depth. The water-cooled 4-cylinder engine provides consistent power delivery through variable piston hydraulic pumps, while the 99 kN bucket digging force handles tough excavation tasks efficiently. With 250L fuel capacity and dual travel speeds (3.4/5.5 km/h), productivity remains high throughout extended shifts.
- 12-ton class excavator with proven ISUZU diesel engine
- 4.6m boom and 2.52m arm configuration for versatile reach
- Compact transport dimensions: 7,610 mm × 2,490 mm × 2,740 mm
- 70% gradeability and 37 Kpa ground pressure for varied terrain
- Cost-effective alternative to new equipment without compromising capability
| Specifications | Value |
|---|---|
| No. | 1009597 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12200 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4.6 |
| Rod length (mm) | 2.52 |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4BG1TC |
| Rated power (kw/rpm) | 66/2150 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 13.7 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 99 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 3.4/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Quantitative plunger pump ×1 |
| Type of walking hydraulic motor | Variable piston pump ×2 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable piston pump ×2+ gear pump ×1 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 69(Full box 130) |
| Engine Oil changes (L) | 15.8 |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2740 |
| Full cab height (mm) | 2740 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 2880 |
| Maximum digging radius (mm) | 8270 |
| Maximum digging depth (mm) | 5570 |
| Maximum excavation height (mm) | 8570 |
| Maximum unloading height (mm) | 6160 |
| Maximum vertical digging depth (mm) | 5020 |
| Bulldozer lift or depth (mm) | No bulldozer |
