Product Description
Built for demanding excavation work, this 2015 Hitachi ZX120 delivers reliable performance across construction and earthmoving applications. Operating at 12 tons with a 66kW ISUZU engine, this machine handles digging, grading, and material handling with proven efficiency. The 0.52m³ backhoe bucket generates 99kN of digging force, while the 8270mm maximum reach and 5570mm digging depth provide extensive working range for foundation work, trenching, and site preparation.
Equipped with variable piston hydraulic pumps and water-cooled direct injection power, this excavator maintains consistent output during extended operations. Track dimensions of 2880mm ground contact length and 500mm plate width ensure 37kPa ground pressure for stable performance on varied terrain. The 4.6m boom and 2.52m arm configuration optimize cycle times for loading trucks and precise grading work.
- 12-ton operating weight with 12,200kg working capacity
- ISUZU 4-cylinder engine: 66kW at 2150rpm
- Maximum digging depth: 5570mm
- Bucket digging force: 99kN
- 250L fuel capacity for extended shifts
- Located in Liuzhou, Guangxi—ready for immediate deployment
| Specifications | Value |
|---|---|
| No. | 994214 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12200 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4.6 |
| Rod length (mm) | 2.52 |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4BG1TC |
| Rated power (kw/rpm) | 66/2150 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 13.7 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 99 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 3.4/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Quantitative plunger pump ×1 |
| Type of walking hydraulic motor | Variable piston pump ×2 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable piston pump ×2+ gear pump ×1 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 69(Full box 130) |
| Engine Oil changes (L) | 15.8 |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2740 |
| Full cab height (mm) | 2740 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 2880 |
| Maximum digging radius (mm) | 8270 |
| Maximum digging depth (mm) | 5570 |
| Maximum excavation height (mm) | 8570 |
| Maximum unloading height (mm) | 6160 |
| Maximum vertical digging depth (mm) | 5020 |
| Bulldozer lift or depth (mm) | No bulldozer |
