Product Description
Built to withstand the demands of heavy construction, this 2016 Hitachi ZX120 excavator represents proven engineering excellence from one of the industry's most trusted manufacturers. Operating at 12 tons with a robust 12,200 kg working weight, this machine delivers consistent performance powered by its reliable ISUZU CC-4BG1TC engine, generating 66 kW at 2150 rpm through a water-cooled, 4-cylinder configuration.
Engineered for versatility and endurance, this workhorse features a 0.52 m³ backhoe bucket capacity with impressive digging force specifications: 99 kN bucket force and 65 kN rod force. With a maximum digging radius of 8,270 mm and depth reaching 5,570 mm, it tackles challenging excavation tasks with precision. The hydraulic system, featuring variable piston pumps and a 34.3 Mpa main overflow pressure, ensures smooth, powerful operation across diverse job sites.
- Proven ISUZU engine with 4.329L displacement
- Compact transport dimensions: 7,610 mm × 2,490 mm × 2,740 mm
- Dual travel speeds: 3.4/5.5 km/h for optimal maneuverability
- Currently located in Shenzhen, Guangdong
- 70% climbing ability for challenging terrain
| Specifications | Value |
|---|---|
| No. | 1005174 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12200 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4.6 |
| Rod length (mm) | 2.52 |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4BG1TC |
| Rated power (kw/rpm) | 66/2150 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 13.7 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 99 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 3.4/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Quantitative plunger pump ×1 |
| Type of walking hydraulic motor | Variable piston pump ×2 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable piston pump ×2+ gear pump ×1 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 69(Full box 130) |
| Engine Oil changes (L) | 15.8 |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2740 |
| Full cab height (mm) | 2740 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 2880 |
| Maximum digging radius (mm) | 8270 |
| Maximum digging depth (mm) | 5570 |
| Maximum excavation height (mm) | 8570 |
| Maximum unloading height (mm) | 6160 |
| Maximum vertical digging depth (mm) | 5020 |
| Bulldozer lift or depth (mm) | No bulldozer |
