Product Description
Maximize your equipment budget with this 2016 Hitachi ZX120 excavator from Jiangsu—a proven performer delivering exceptional value without the premium price tag of new machinery. Operating at 12 tons with a robust 12,200 kg working weight, this mid-size excavator combines reliability with cost-effective productivity for contractors seeking smart capital allocation.
Powered by an ISUZU CC-4BG1TC engine generating 66 kW at 2,150 rpm, this machine offers dependable performance across demanding jobsites. The 0.52 m³ bucket capacity, paired with 99 kN bucket digging force and 65 kN rod digging force, ensures efficient material handling and excavation. With a maximum digging reach of 8,270 mm and depth of 5,570 mm, operational versatility matches that of comparable new units at a fraction of the investment.
- Working Weight: 12,200 kg with 4.6m boom and 2.52m rod configuration
- Hydraulic System: Dual variable piston pumps with 34.3 MPa main overflow pressure
- Mobility: 3.4/5.5 km/h travel speeds with 70% climbing capability
- Fuel Efficiency: 250L tank capacity for extended operation
- Compact Transport: 7,610 mm length × 2,490 mm width dimensions
Reduce acquisition costs si
| Specifications | Value |
|---|---|
| No. | 1008974 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12200 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4.6 |
| Rod length (mm) | 2.52 |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4BG1TC |
| Rated power (kw/rpm) | 66/2150 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 13.7 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 99 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 3.4/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Quantitative plunger pump ×1 |
| Type of walking hydraulic motor | Variable piston pump ×2 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable piston pump ×2+ gear pump ×1 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 69(Full box 130) |
| Engine Oil changes (L) | 15.8 |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2740 |
| Full cab height (mm) | 2740 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 2880 |
| Maximum digging radius (mm) | 8270 |
| Maximum digging depth (mm) | 5570 |
| Maximum excavation height (mm) | 8570 |
| Maximum unloading height (mm) | 6160 |
| Maximum vertical digging depth (mm) | 5020 |
| Bulldozer lift or depth (mm) | No bulldozer |
