Product Description
Proven reliability meets compact versatility in this 2017 Hitachi ZX17U-2 mini excavator, currently located in Jiangsu. Operating at 1.8 tons with a Yanmar 3TNV70 engine delivering 11.0 kW at 2400 rpm, this joint-venture manufactured machine combines Japanese engineering standards with practical performance for confined jobsites. Hitachi's established global parts network ensures maintenance continuity, while the brand's reputation for durability protects your investment with strong resale value in secondary markets.
- Compact Dimensions: 3590mm length × 980mm width, ideal for urban construction and landscaping projects
- Working Capacity: Maximum digging depth of 2170mm with 3900mm reach radius
- Hydraulic Performance: 16 kN bucket digging force, dual 19.2 l/min pumps operating at 20.6 Mpa
- Efficient Operation: 19.5L fuel tank, variable travel speeds 2.4-4.3 km/h
- Versatile Bucket Range: 0.020-0.050 m³ capacity for varied applications
Backed by Hitachi's dealer support infrastructure and readily available OEM components, this ZX17U-2 represents a calculated investment in proven micro-excavato
| Specifications | Value |
|---|---|
| No. | 1021358 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1850 |
| Bucket capacity (m³) | 0.020 - 0.050 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 3TNV70 |
| Rated power (kw/rpm) | 11.0/2400 |
| Cylinder diameter × stroke (mm) | 70 x 74 |
| Displacement (L) | 0.854 |
| Bucket digging force (kN) | 16 |
| Rod digging force (kN) | 10.3 |
| Travel speed (km/h) | 2.4-4.3 |
| Turning torque (Nm) | 50.2 |
| Main overflow set pressure (Mpa) | 20.6 |
| Maximum flow of main pump (l/min) | 2 x 19.2 |
| Bucket cylinders - Number × diameter × stroke (mm) | 60 x 94 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 60 x 311 |
| Boom cylinders - Number × diameter × stroke (mm) | 60 x 406 |
| Fuel Tank (L) | 19.5 |
| Engine Oil changes (L) | 3.1 |
| Coolant (L) | 15.7 |
| Total transport length (mm) | 3590 |
| Total transport width (mm) | 980 |
| Total transport height (mm) | 2400 |
| Minimum ground clearance (mm) | 165 |
| Back end turning radius (mm) | 1610 |
| Track gauge (mm) | 1210 |
| Track plate width (mm) | 2230 |
| Maximum digging radius (mm) | 3900 |
| Maximum digging depth (mm) | 2170 |
| Maximum excavation height (mm) | 3560 |
| Maximum unloading height (mm) | 2530 |
