Product Description
Available now in Zhejiang Shaoxing, this 2018 Hitachi ZX18U-2 mini excavator eliminates factory wait times and gets your project moving immediately. Compact yet capable, this 1.85-ton machine delivers exceptional maneuverability in tight urban spaces with its ultra-narrow 1,280mm transport width and minimal 675mm tail swing radius. Fast deployment to your site means you're operational within days, not months.
- Engine: Yanmar 3TNV70, 11kW at 2,400 rpm—proven reliability for demanding applications
- Performance: 2,170mm maximum digging depth, 3,560mm reach height, 0.04m³ bucket capacity
- Mobility: 4.3 km/h travel speed, 1,210mm track ground contact for superior stability
- Efficiency: 19.5L fuel tank, 30L hydraulic system, optimized for extended operation
- Dimensions: 3,590mm length × 2,400mm height—ideal for transport and confined jobsites
Skip the factory lead times. This ready-to-work machine in Shaoxing offers immediate availability for contractors who need results now. Inspect today, deploy tomorrow.
| Specifications | Value |
|---|---|
| No. | 1049649 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1850 |
| Bucket capacity (m³) | 0.04 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 3TNV70 |
| Rated power (kw/rpm) | 11/2400 |
| Displacement (L) | 0.85 |
| Ground specific pressure (Kpa) | 28 |
| Travel speed (km/h) | 4.3 |
| Fuel Tank (L) | 19.5 |
| Engine Oil changes (L) | 3.1 |
| Coolant (L) | 2.7 |
| Hydraulic System (L) | 30 |
| Total transport length (mm) | 3590 |
| Total transport width (mm) | 1280 |
| Total transport height (mm) | 2400 |
| Full cab height (mm) | 2400 |
| Minimum ground clearance (mm) | 165 |
| Back end turning radius (mm) | 675 |
| Track gauge (mm) | 1050 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1210 |
| Maximum digging depth (mm) | 2170 |
| Maximum excavation height (mm) | 3560 |
| Maximum unloading height (mm) | 2530 |
| Maximum vertical digging depth (mm) | 1830 |
