Product Description
Proven reliability meets exceptional value in this 2018 Hitachi ZX210K-5A, a 21-ton excavator engineered for demanding jobsites worldwide. Powered by the robust Isuzu 4HK1 engine delivering 113kW at 2000rpm, this machine combines fuel efficiency with consistent performance across extended duty cycles. Hitachi's legendary build quality ensures superior parts availability and strong resale value—critical factors when investing in used heavy equipment.
Located in Hunan, this backhoe excavator offers impressive operational capabilities:
- Reach & Depth: 9,920mm maximum digging radius, 6,670mm maximum digging depth
- Hydraulic Power: 158kN bucket digging force with dual variable axial piston pumps
- Versatility: 0.91-1.0m³ bucket capacity, 70% grading ability
- Efficiency: 400L fuel tank, water-cooled turbocharged engine with intercooling
- Serviceability: Joint venture/import manufacturing ensures genuine parts access globally
Hitachi excavators maintain exceptional residual values due to their durability and widespread dealer networks. For contractors seeking dependable performance with low
| Specifications | Value |
|---|---|
| No. | 1046852 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21000~21100 |
| Bucket capacity (m³) | 0.91~1.0 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu GI-4HK1XKSA-02 |
| Rated power (kw/rpm) | 113 / 2000 |
| Cooling mode | water-cooling |
| Displacement (L) | 5.193 |
| Working form | 4 stroke, water cooled, electronically controlled injection, turbocharged, intercooled |
| Ground specific pressure (Kpa) | 47 |
| Rotation speed (rpm) | 13.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 158 |
| Rod digging force (kN) | 114 |
| Travel speed (km/h) | 5.5 / 3.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | 1 axial plunger motor |
| Type of walking hydraulic motor | 2 variable axial piston motors |
| Main pump type | 2 variable axial piston pumps, 1 gear pump |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 200 |
| Engine Oil changes (L) | 23 |
| Total transport length (mm) | 9660 |
| Total transport width (mm) | 2880 |
| Total transport height (mm) | 3010 |
| Counterweight ground clearance (mm) | 1030 |
| Minimum ground clearance (mm) | 450 |
| Minimum turning radius of front working device (mm) | 3180 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4170 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Maximum digging radius (mm) | 9920 |
| Maximum digging depth (mm) | 6670 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 7180 |
| Maximum vertical digging depth (mm) | 5990 |
| Maximum excavation radius of stop surface (mm) | 9750 |
