Product Description

Expand your operational capacity with this 2018 Hitachi ZX210K-5A excavator, a proven 21-ton workhorse engineered for contractors managing multiple job sites simultaneously. Powered by a robust Isuzu 4HK1XKSA-02 engine delivering 113 kW at 2000 rpm, this machine provides consistent performance when your primary fleet is stretched thin. The water-cooled, turbocharged, intercooled powerplant ensures reliable output across demanding applications.

  • Bucket digging force: 158 kN with 0.91-1.0 m³ capacity
  • Maximum digging reach: 9,920 mm; depth: 6,670 mm
  • Dual variable axial piston pumps for responsive hydraulics
  • 400 L fuel tank minimizes refueling downtime
  • 70% grading ability handles steep terrain
  • Currently located in Guizhou, China

With dual variable axial piston walking motors and a 13.5 rpm rotation speed, this ZX210K-5A integrates seamlessly into existing Hitachi fleets or serves as a dependable backup unit. Transport dimensions of 9,660 × 2,880 × 3,010 mm facilitate straightforward logistics between projects.

SpecificationsValue
No.1046918
Tonnage (tons)21
Working weight (kg)21000~21100
Bucket capacity (m³)0.91~1.0
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeIsuzu GI-4HK1XKSA-02
Rated power (kw/rpm)113 / 2000
Cooling modewater-cooling
Displacement (L)5.193
Working form4 stroke, water cooled, electronically controlled injection, turbocharged, intercooled
Ground specific pressure (Kpa)47
Rotation speed (rpm)13.5
Climbing ability (%)70
Bucket digging force (kN)158
Rod digging force (kN)114
Travel speed (km/h)5.5 / 3.5
Main overflow set pressure (Mpa)34.3
Rotary hydraulic motor type1 axial plunger motor
Type of walking hydraulic motor2 variable axial piston motors
Main pump type2 variable axial piston pumps, 1 gear pump
Fuel Tank (L)400
Hydraulic Tank (L)200
Engine Oil changes (L)23
Total transport length (mm)9660
Total transport width (mm)2880
Total transport height (mm)3010
Counterweight ground clearance (mm)1030
Minimum ground clearance (mm)450
Minimum turning radius of front working device (mm)3180
Back end turning radius (mm)2890
Total track length (mm)4170
Track gauge (mm)2200
Track plate width (mm)600
Maximum digging radius (mm)9920
Maximum digging depth (mm)6670
Maximum excavation height (mm)10040
Maximum unloading height (mm)7180
Maximum vertical digging depth (mm)5990
Maximum excavation radius of stop surface (mm)9750
see more

Overview

No.1046918

Brand Name:

Hitachi

Model Number:

ZX210K-5A

Year:

2018

Location:

Guizhou China
