2018 Hitachi ZX210K-5A

1/6
Buy Hitachi ZX210K-5A Used Excavator / 1
Buy Hitachi ZX210K-5A Used Excavator / 2
Buy Hitachi ZX210K-5A Used Excavator / 3
Buy Hitachi ZX210K-5A Used Excavator / 4
Buy Hitachi ZX210K-5A Used Excavator / 5
Buy Hitachi ZX210K-5A Used Excavator / 6

Product Description

Maximize your equipment budget with this 2018 Hitachi ZX210K-5A excavator from Zhejiang Jinhua. Delivering 21-ton performance at a fraction of new-equipment costs, this machine proves smart investment means choosing proven reliability over depreciation. Powered by an Isuzu 4HK1XKSA-02 engine producing 113kW at 2000rpm, it combines robust digging force (158kN bucket, 114kN arm) with efficient water-cooled, turbocharged operation. Its 9.92m maximum reach and 6.67m digging depth handle demanding applications across construction and earthmoving projects.

  • Operating Weight: 21,000-21,100 kg with 0.91-1.0m³ bucket capacity
  • Hydraulic System: Dual variable axial piston pumps, 34.3MPa pressure for responsive control
  • Fuel Efficiency: 400L fuel tank, 5.193L displacement for extended operation
  • Mobility: 5.5/3.5 km/h travel speeds, 70% gradeability, 2880mm transport width
  • Capacity: 10.04m max excavation height, 7.18m unloading height

Joint-venture quality engineering meets cost-effective ownership. Secure high-specification performance without premium pricing.

SpecificationsValue
No.1047015
Tonnage (tons)21
Working weight (kg)21000~21100
Bucket capacity (m³)0.91~1.0
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeIsuzu GI-4HK1XKSA-02
Rated power (kw/rpm)113 / 2000
Cooling modewater-cooling
Displacement (L)5.193
Working form4 stroke, water cooled, electronically controlled injection, turbocharged, intercooled
Ground specific pressure (Kpa)47
Rotation speed (rpm)13.5
Climbing ability (%)70
Bucket digging force (kN)158
Rod digging force (kN)114
Travel speed (km/h)5.5 / 3.5
Main overflow set pressure (Mpa)34.3
Rotary hydraulic motor type1 axial plunger motor
Type of walking hydraulic motor2 variable axial piston motors
Main pump type2 variable axial piston pumps, 1 gear pump
Fuel Tank (L)400
Hydraulic Tank (L)200
Engine Oil changes (L)23
Total transport length (mm)9660
Total transport width (mm)2880
Total transport height (mm)3010
Counterweight ground clearance (mm)1030
Minimum ground clearance (mm)450
Minimum turning radius of front working device (mm)3180
Back end turning radius (mm)2890
Total track length (mm)4170
Track gauge (mm)2200
Track plate width (mm)600
Maximum digging radius (mm)9920
Maximum digging depth (mm)6670
Maximum excavation height (mm)10040
Maximum unloading height (mm)7180
Maximum vertical digging depth (mm)5990
Maximum excavation radius of stop surface (mm)9750
see more

Overview

No.1047015

Brand Name:

Hitachi

Model Number:

ZX210K-5A

Year:

2018

Location:

Zhejiang China
