Product Description
FairTradeMachinery presents two premium 2018 Hitachi ZX330-5A hydraulic excavators, currently located in Zhejiang, China. These well-maintained units represent Hitachi's renowned 5A series, engineered for demanding earthmoving and construction applications. With approximately 8 years of operational history, both machines have been rigorously inspected and demonstrate excellent working condition with performance parameters meeting factory standards.
Key features of the ZX330-5A include:
- 33-ton operating weight class for versatile mid-size applications
- Fuel-efficient Isuzu engine with advanced hydraulic systems
- Enhanced operator cabin with improved visibility and ergonomics
- Durable undercarriage and reinforced boom structure
- Ideal for excavation, loading, and material handling operations
These units are available for immediate inspection and export. Suitable for contractors seeking reliable, proven equipment with substantial service life remaining. Contact our sales team for detailed specifications, pricing, and shipping arrangements.
| Specifications | Value |
|---|---|
| No. | 1083701 |
| Tonnage (tons) | 33 |
| Working weight (kg) | 32700 |
| Bucket capacity (m³) | 1.45-1.62 |
| Boom length (mm) | 6400 |
| Rod length (mm) | 3200 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu GH-6HK1XKSA-01 |
| Rated power (kw/rpm) | 190/1900 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 115 x 125 |
| Maximum torque (N.m) | 1037/1500 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.790 |
| Working form | 4 stroke, water cooled, electrically controlled direct injection, turbocharged, intercooled |
| Ground specific pressure (Kpa) | 66 |
| Rotation speed (rpm) | 10.7 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 246 |
| Rod digging force (kN) | 185 |
| Maximum tractive force (kN) | 298 |
| Travel speed (km/h) | 3.2-5.0 |
| Turning torque (Nm) | 120 |
| Rotary hydraulic motor type | 1 swashplate plunger motor |
| Type of walking hydraulic motor | 2 variable swash plate plunger motor |
| Maximum flow of main pump (l/min) | 2 x 288 |
| Traveling Hydraulic Circuit (Mpa) | 34.8 |
| Rotary Hydraulic Circuit (Mpa) | 32.4 |
| Main pump type | 2 variable axial piston pumps |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Pilot pump flow (L/min) | 30.2 |
| Pilot pump type | 1 gear pump |
| Fuel Tank (L) | 630 |
| Hydraulic Tank (L) | 180 |
| Engine Oil changes (L) | 41 |
| Coolant (L) | 35 |
| Hydraulic System (L) | 340 |
| Total transport length (mm) | 11220 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3270 |
| Full cab height (mm) | 3160 |
| Counterweight ground clearance (mm) | 1160 |
| Minimum ground clearance (mm) | 500 |
| Minimum turning radius of front working device (mm) | 4610 |
| Back end turning radius (mm) | 3590 |
| Onboard width (mm) | 2990 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 3730 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 11100 |
| Maximum digging depth (mm) | 7380 |
| Maximum excavation height (mm) | 10360 |
| Maximum unloading height (mm) | 7240 |
| Maximum vertical digging depth (mm) | 6420 |
| Maximum excavation radius of stop surface (mm) | 10890 |
