Product Description
Built for demanding excavation projects, this 2016 Hitachi ZX450 delivers exceptional operator control through proven engineering and intelligent design. Operating at 45 tons with a robust Isuzu AA-6WG1TQA engine producing 234.1 kW, this machine combines raw power with precision handling across diverse job sites.
Operators benefit from superior stability courtesy of the 4,050 mm track ground length and 2,740 mm track gauge, ensuring confident performance on challenging terrain. Ground-specific pressure of just 79 kPa minimizes surface impact while maintaining excellent traction. Cabin positioning at 3,260 mm height provides commanding visibility across the 10,340 mm maximum excavation radius, allowing operators to monitor bucket placement and site conditions with clarity.
- Responsive hydraulic system (510 L capacity) for smooth, controlled movements
- Spacious operator compartment with optimized sightlines to work zones
- 1.9 m³ standard bucket capacity with versatile 1.2/2.7 m³ options
- Maximum digging depth of 6,020 mm for deep excavation work
- 650 L fuel tank supporting extended operational shifts
Currently located in Shaoxing, Zhejiang, this joint-venture manufact
| Specifications | Value |
|---|---|
| No. | 1032189 |
| Tonnage (tons) | 45 |
| Working weight (kg) | 42500 |
| Bucket capacity (m³) | 1.9/1.2/2.7 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu AA-6WG1TQA |
| Rated power (kw/rpm) | 234.1/1800 |
| Displacement (L) | 15.7 |
| Ground specific pressure (Kpa) | 79 |
| Travel speed (km/h) | 5.5 |
| Fuel Tank (L) | 650 |
| Engine Oil changes (L) | 55 |
| Coolant (L) | 61 |
| Hydraulic System (L) | 510 |
| Total transport length (mm) | 11850 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3260 |
| Full cab height (mm) | 3260 |
| Counterweight ground clearance (mm) | 1230 |
| Minimum ground clearance (mm) | 496 |
| Back end turning radius (mm) | 3500 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4050 |
| Maximum digging depth (mm) | 6020 |
| Maximum excavation height (mm) | 10620 |
| Maximum unloading height (mm) | 7100 |
| Maximum vertical digging depth (mm) | 4810 |
| Maximum excavation radius of stop surface (mm) | 10340 |
