Product Description
Available now in Guizhou, this 2011 Hitachi ZX60 mini excavator eliminates factory wait times and gets your project moving immediately. Built at Hitachi's Hefei facility with proven ISUZU CC-4JG1 power, this 5,850 kg machine delivers reliable performance across construction, landscaping, and municipal applications. Fast deployment means you're operational within days, not months.
- 6-ton class: 0.22 m³ bucket capacity with 41.4 kN digging force
- Compact footprint: 2,060 mm transport width, 2,510 mm front turning radius
- Versatile reach: 6,250 mm maximum dig radius, 3,850 mm depth capability
- ISUZU diesel: 40.5 kW water-cooled engine, dual variable piston pumps
- Proven mobility: 70% grading ability, 4.5 km/h high-speed travel
Ready for immediate inspection and shipment from Guizhou. Skip extended lead times—secure this field-tested ZX60 and accelerate your project timeline. Contact Fair Trade Machinery today for export documentation and logistics coordination to your site worldwide.
| Specifications | Value |
|---|---|
| No. | 1011841 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
