Product Description
With a working weight of 5850 kg and a bucket capacity of 0.22 m³, this 2012 Hitachi ZX60 excavator is designed for efficient digging, grading, and demolition tasks. Powered by a robust ISUZU CC-4JG1 engine, it delivers 40.5 kW at 2100 rpm, ensuring reliable performance on any site. Equipped with a 3.49 mm boom and an enhanced 1.6 mm rod, this machine provides a maximum digging depth of 3850 mm and a maximum digging radius of 6250 mm, making it ideal for a variety of construction needs.
- Bucket digging force: 41.4 kN
- Travel speed: 2.5/4.5 km/h
- Ground specific pressure: 33 Kpa
- Fuel tank capacity: 120 L
- Track gauge: 1600 mm
Located in Dali Bai Autonomous Prefecture, Yunnan, this excavator is ready to work immediately, offering the durability and versatility needed for your next project. Its compact design and powerful performance make it an excellent choice for both small and large-scale operations.
| Specifications | Value |
|---|---|
| No. | 1000368 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
