Product Description
Built to endure the toughest jobsite conditions, this 2017 Hitachi ZX60 mini excavator demonstrates proven reliability through years of consistent performance. Operating at 5,850 kg working weight with a robust 0.22 m³ bucket capacity, this compact powerhouse delivers exceptional digging force—41.4 kN bucket force and 28.4 kN arm force—making light work of demanding excavation tasks. Powered by a dependable ISUZU CC-4JG1 engine producing 40.5 kW at 2100 rpm, this machine combines efficiency with raw capability.
Currently located in Ganzhou, Jiangxi, this workhorse features enhanced rod length (1.6 m) for extended reach, achieving a maximum digging radius of 6,250 mm and depth of 3,850 mm. Its water-cooled, 4-cylinder direct injection engine ensures optimal thermal management during extended operations. With a 70% climbing ability and dual variable piston pumps, this ZX60 maintains hydraulic performance under pressure.
- Proven ISUZU engine with 3.059L displacement
- Compact dimensions: 6,060 mm length × 2,060 mm width
- Dual-speed travel: 2.5/4.5 km/h for versatile mobility
- 120L fuel capacity for extended runtime
- 400 mm track plates for superior stability
| Specifications | Value |
|---|---|
| No. | 1007371 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
