Product Description
With a working weight of 5850 kg and powered by a reliable ISUZU CC-4JG1 engine, this 2018 Hitachi ZX60 excavator is ready for immediate deployment. Located in 浙江杭州, it offers a bucket capacity of 0.22 m³ and an enhanced rod length of 1.6 mm, ensuring efficient performance on any job site. Skip the factory lead times and get your project moving with fast delivery to your location. This compact yet powerful machine boasts a maximum digging depth of 3850 mm and a travel speed of up to 4.5 km/h, making it ideal for tight spaces and demanding tasks. Available now, the ZX60 is equipped with a 120-liter fuel tank and a 61-liter hydraulic tank, providing ample capacity for extended operation.
- Working weight: 5850 kg
- Bucket capacity: 0.22 m³
- Maximum digging depth: 3850 mm
- Travel speed: 2.5/4.5 km/h
- Engine: ISUZU CC-4JG1, 40.5 kW at 2100 rpm
- Fuel tank: 120 L
- Hydraulic tank: 61 L (full box 95 L)
| Specifications | Value |
|---|---|
| No. | 1001015 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
