Product Description
With a working weight of 5850 kg and a bucket capacity of 0.22 m³, this 2019 Hitachi ZX60 excavator is an ideal fleet addition for busy contractors. Manufactured in Hefei, Anhui Province, it features a robust ISUZU CC-4JG1 engine, delivering 40.5 kW at 2100 rpm. The machine offers a maximum digging depth of 3850 mm and a maximum unloading height of 4080 mm, ensuring versatility on any job site.
- Enhanced boom length of 3.49 meters and rod length of 1.6 meters
- Direct injection, water-cooled, 4-cylinder engine with 3.059 L displacement
- Travel speed of 2.5/4.5 km/h and a climbing ability of 70% or 35°
- Bucket and rod digging forces of 41.4 kN and 28.4 kN respectively
- Equipped with a variable piston pump and axial piston motor for efficient hydraulic performance
Located in 江西, this unit is ready to integrate into your existing fleet, providing reliable support and enhancing overall productivity.
| Specifications | Value |
|---|---|
| No. | 1003799 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
