Product Description
Expand your fleet capacity with this 2019 Hitachi ZX60 mini excavator, currently located in Shaoxing, Zhejiang. Powered by a reliable ISUZU CC-4JG1 engine delivering 40.5kW at 2100rpm, this 6-ton machine offers the performance consistency busy contractors demand when primary units are committed to other sites.
Built at Hitachi's Hefei facility, this compact workhorse combines a 0.22m³ bucket capacity with impressive reach specifications—6,250mm maximum digging radius and 3,850mm maximum digging depth. Variable piston pumps and axial piston rotation motor provide precise hydraulic control for detail work or trenching operations.
- Operating weight: 5,850kg with 400mm track plates for stable operation
- Dual-speed travel: 2.5/4.5 km/h for efficient site repositioning
- Compact transport dimensions: 6,060mm × 2,060mm × 2,470mm
- 41.4kN bucket digging force and 28.4kN arm digging force
- 120L fuel tank and 61L hydraulic reservoir minimize refill downtime
Ideal for contractors running multiple jobsites simultaneously, this unit ensures project continuity when equipment rotation is critical to maintaining schedules.
| Specifications | Value |
|---|---|
| No. | 1017325 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
