Product Description
Built for endurance and field-proven reliability, this 2019 Hitachi ZX60 mini excavator delivers consistent performance across demanding job sites. With over five years of operational history, this 6-ton workhorse demonstrates the legendary durability Hitachi engineering is known for worldwide. Powered by a robust ISUZU CC-4JG1 water-cooled engine producing 40.5 kW at 2100 rpm, this machine combines fuel efficiency with unwavering power delivery.
Currently located in Guizhou, this compact excavator offers impressive capabilities within a transport-friendly footprint. Equipped with a 0.22 m³ backhoe bucket, it reaches a maximum digging depth of 3,850 mm and an exceptional digging radius of 6,250 mm. The variable piston pump hydraulic system ensures precise control, while bucket digging force of 41.4 kN tackles tough materials with confidence.
- Operating Weight: 5,850 kg with superior stability
- Enhanced rod length: 1.6 m for extended reach
- Impressive 70% (35°) climbing ability
- Compact dimensions: 6,060 mm × 2,060 mm × 2,470 mm
- Fuel capacity: 120L for extended operation
- Minimal ground pressure: 33 kPa reduces surface damage
Manufactured as a joint venture
| Specifications | Value |
|---|---|
| No. | 1025596 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
