Product Description
Built for demanding jobsites, this 2020 Hyundai 110LVS excavator delivers proven performance backed by one of the industry's most trusted names. Operating at 11 tons with a robust 0.45m³ bucket capacity, this machine combines a Mitsubishi 4FRC engine producing 74kW at 2000 rpm with dual variable plunger pumps for consistent hydraulic power. Maximum digging depth reaches 5090mm, while the 7740mm working radius handles diverse excavation tasks with authority.
Hyundai's reputation in the used equipment market stands on solid ground. Parts availability remains exceptional across global networks, minimizing downtime and keeping operational costs predictable. Resale values consistently outperform competitors due to the brand's joint venture manufacturing standards and proven durability. Located in Hunan, this unit represents a strategic investment where brand recognition translates directly to long-term value retention.
Key specifications include:
- 4300mm boom and 2260mm arm configuration for optimal reach
- 330 Mpa working hydraulic circuit with 2×112 l/min flow capacity
- 250L fuel tank supporting extended operation cycles
- 70% climbing ability for challenging terrain navigation
| Specifications | Value |
|---|---|
| No. | 993557 |
| Tonnage (tons) | 11 |
| Bucket capacity (m³) | 0.45m3 |
| Boom length (mm) | 4300mm |
| Rod length (mm) | 2260mm |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | MITSUBISHI 4FRC |
| Rated power (kw/rpm) | 99(74) / 2000 |
| Cylinder diameter × stroke (mm) | 102 (4.02) x 130 (5.12) |
| Maximum torque (N.m) | 43.5(315) / 1350 |
| Displacement (L) | 4.2 |
| Working form | 4 cylinder 4 stroke water cooled direct injection engine |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.5 km/h (3.4 mph) / 3.4 km/h (2.1 mph) |
| Maximum flow of main pump (l/min) | 2×112 (2×29.6) |
| Traveling Hydraulic Circuit (Mpa) | 330 |
| Rotary Hydraulic Circuit (Mpa) | 240 |
| Main pump type | Two variable plunger pump |
| Working Hydraulic Circuit (Mpa) | 330 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-95 x 65 x 855 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-110 x 75 x 1070 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-95 x 70 x 1015 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 100 |
| Engine Oil changes (L) | 17.5 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 210 |
| Full cab height (mm) | 2800 |
| Counterweight ground clearance (mm) | 900 |
| Back end turning radius (mm) | 2380mm |
| Total track length (mm) | 7270 |
| Total track width (mm) | 2490 |
| Maximum digging radius (mm) | 7740mm |
| Maximum digging depth (mm) | 5090mm |
| Maximum excavation height (mm) | 8070mm |
| Maximum unloading height (mm) | 5710mm |
| Maximum vertical digging depth (mm) | 4430mm |
| Maximum excavation radius of stop surface (mm) | 7610mm |
