Product Description
Featuring a robust MITSUBISHI 4FRC engine, this 2016 Hyundai 130LVS excavator delivers reliable performance with a rated power of 131 kW at 2200 rpm. With a tonnage of 13 tons and a bucket capacity ranging from 0.3 to 0.59 m³, it is well-suited for a variety of construction tasks. Located in 福建莆田, this excavator offers a maximum digging depth of 5550 mm and a maximum digging radius of 8330 mm, ensuring efficient and versatile operation.
- Hyundai's global reputation for durability and reliability makes this model a solid choice in the used market.
- Parts availability is extensive, ensuring minimal downtime and easy maintenance.
- High resale value due to Hyundai's strong brand presence and consistent performance.
- Equipped with a two-variable plunger pump, providing a maximum flow of 2 x 124 l/min for smooth and powerful operation.
- Travel speed options of 5.5 km/h and 3.2 km/h, along with a 70% climbing ability, enhance its mobility on various terrains.
| Specifications | Value |
|---|---|
| No. | 1004341 |
| Tonnage (tons) | 13 |
| Bucket capacity (m³) | 0.3-0.59m3 |
| Boom length (mm) | 4300mm |
| Rod length (mm) | 2260mm |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | MITSUBISHI 4FRC |
| Rated power (kw/rpm) | 131(98) / 2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 (4.0) x 120 (4.7) |
| Displacement (L) | 4.2 |
| Working form | 4 cylinder 4 stroke water cooled direct injection engine |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.5 km/h (3.4 mph) / 3.2 km/h (2.0 mph) |
| Maximum flow of main pump (l/min) | 2 x 124 |
| Traveling Hydraulic Circuit (Mpa) | 365 |
| Rotary Hydraulic Circuit (Mpa) | 285 |
| Main pump type | Two variable plunger pump |
| Working Hydraulic Circuit (Mpa) | 350 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-100 x 70 x 840 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-115 x 80 x 1138 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-105 x 75 x 1075 |
| Fuel Tank (L) | 270 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 17.5 |
| Hydraulic System (L) | 210 |
| Total transport height (mm) | 8330 |
| Counterweight ground clearance (mm) | 935 |
| Back end turning radius (mm) | 2310 |
| Onboard width (mm) | 2476 |
| Total track length (mm) | 4300 |
| Total track width (mm) | 2500 |
| Maximum digging radius (mm) | 8330mm |
| Maximum digging depth (mm) | 5550mm |
| Maximum excavation height (mm) | 8500mm |
| Maximum unloading height (mm) | 6060mm |
| Maximum vertical digging depth (mm) | 5330mm |
| Maximum excavation radius of stop surface (mm) | 8180mm |
