Product Description
Built for immediate deployment on demanding jobsites, this 2018 Hyundai 130LVS excavator delivers 13-ton performance with proven MITSUBISHI 4FRC power. Rated at 98kW (131 hp) and equipped with dual variable plunger pumps flowing 2 x 124 L/min, this machine tackles digging, grading, and demolition tasks without hesitation. Maximum digging depth reaches 5,550mm while the 8,330mm working radius covers substantial ground per cycle.
- Backhoe bucket capacity: 0.3-0.59m³ for versatile material handling
- 4,300mm boom and 2,260mm stick optimize reach and breakout force
- Water-cooled 4.2L engine maintains consistent power in extended operations
- 350 MPa working hydraulic circuit supports heavy breakout applications
- 5.5 km/h travel speed ensures efficient site-to-site repositioning
- 270L fuel tank and 124L hydraulic reservoir minimize refueling downtime
- 70% grading ability handles steep terrain and ramp work
Currently located in Sichuan, this joint-venture manufactured excavator combines Japanese engine reliability with proven hydraulic architecture. Machine specifications support full-shift productivity in excavation, foundation work, and material placement operatio
| Specifications | Value |
|---|---|
| No. | 1010835 |
| Tonnage (tons) | 13 |
| Bucket capacity (m³) | 0.3-0.59m3 |
| Boom length (mm) | 4300mm |
| Rod length (mm) | 2260mm |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | MITSUBISHI 4FRC |
| Rated power (kw/rpm) | 131(98) / 2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 (4.0) x 120 (4.7) |
| Displacement (L) | 4.2 |
| Working form | 4 cylinder 4 stroke water cooled direct injection engine |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.5 km/h (3.4 mph) / 3.2 km/h (2.0 mph) |
| Maximum flow of main pump (l/min) | 2 x 124 |
| Traveling Hydraulic Circuit (Mpa) | 365 |
| Rotary Hydraulic Circuit (Mpa) | 285 |
| Main pump type | Two variable plunger pump |
| Working Hydraulic Circuit (Mpa) | 350 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-100 x 70 x 840 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-115 x 80 x 1138 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-105 x 75 x 1075 |
| Fuel Tank (L) | 270 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 17.5 |
| Hydraulic System (L) | 210 |
| Total transport height (mm) | 8330 |
| Counterweight ground clearance (mm) | 935 |
| Back end turning radius (mm) | 2310 |
| Onboard width (mm) | 2476 |
| Total track length (mm) | 4300 |
| Total track width (mm) | 2500 |
| Maximum digging radius (mm) | 8330mm |
| Maximum digging depth (mm) | 5550mm |
| Maximum excavation height (mm) | 8500mm |
| Maximum unloading height (mm) | 6060mm |
| Maximum vertical digging depth (mm) | 5330mm |
| Maximum excavation radius of stop surface (mm) | 8180mm |
