Product Description
Strengthen your fleet with this 2019 Hyundai 130LVS excavator, currently located in Chongqing and ready for immediate deployment. Built for contractors who demand reliable backup capacity, this 13-ton machine delivers consistent performance across demanding jobsites. Powered by a robust MITSUBISHI 4FRC engine producing 98kW at 2200 rpm, this unit combines proven joint venture engineering with practical operational capabilities.
- Maximum digging depth of 5,550mm with 8,330mm reach radius
- Dual variable plunger pumps providing 2 × 124 L/min flow capacity
- 4,300mm boom and 2,260mm arm configuration for versatile applications
- Water-cooled 4.2L displacement engine with 70% climbing ability
- 270L fuel tank and 124L hydraulic reservoir for extended operation
- Compact 2,500mm track width enables maneuverability in confined spaces
Ideal for contractors seeking to expand operational capacity without compromising on quality, this excavator integrates seamlessly into existing fleets. Its proven hydraulic system, standardized maintenance requirements, and reliable Mitsubishi power plant minimize downtime while maximizing productivity across earthmoving, trenching, a
| Specifications | Value |
|---|---|
| No. | 993482 |
| Tonnage (tons) | 13 |
| Bucket capacity (m³) | 0.3-0.59m3 |
| Boom length (mm) | 4300mm |
| Rod length (mm) | 2260mm |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | MITSUBISHI 4FRC |
| Rated power (kw/rpm) | 131(98) / 2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 (4.0) x 120 (4.7) |
| Displacement (L) | 4.2 |
| Working form | 4 cylinder 4 stroke water cooled direct injection engine |
| Climbing ability (%) | 70 |
| Travel speed (km/h) | 5.5 km/h (3.4 mph) / 3.2 km/h (2.0 mph) |
| Maximum flow of main pump (l/min) | 2 x 124 |
| Traveling Hydraulic Circuit (Mpa) | 365 |
| Rotary Hydraulic Circuit (Mpa) | 285 |
| Main pump type | Two variable plunger pump |
| Working Hydraulic Circuit (Mpa) | 350 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-100 x 70 x 840 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-115 x 80 x 1138 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-105 x 75 x 1075 |
| Fuel Tank (L) | 270 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 17.5 |
| Hydraulic System (L) | 210 |
| Total transport height (mm) | 8330 |
| Counterweight ground clearance (mm) | 935 |
| Back end turning radius (mm) | 2310 |
| Onboard width (mm) | 2476 |
| Total track length (mm) | 4300 |
| Total track width (mm) | 2500 |
| Maximum digging radius (mm) | 8330mm |
| Maximum digging depth (mm) | 5550mm |
| Maximum excavation height (mm) | 8500mm |
| Maximum unloading height (mm) | 6060mm |
| Maximum vertical digging depth (mm) | 5330mm |
| Maximum excavation radius of stop surface (mm) | 8180mm |
