Product Description
This 2013 Hyundai 150W-7 wheeled excavator is available from Hubei, China. The machine comes equipped with a hydraulic breaker attachment and quick coupler system, enhancing versatility for demolition and material handling applications. Wheeled excavators of this class typically offer mobility advantages over tracked units, making them suitable for urban construction sites and road maintenance projects.
Key features include:
- Hydraulic breaker attachment included
- Quick coupler system for efficient attachment changes
- Wheeled configuration for improved road travel
- Suitable for demolition, excavation, and material handling
This used machine represents a cost-effective solution for contractors seeking reliable equipment with attachment flexibility. Inspection recommended prior to purchase. Contact us for additional details, operating hours, and shipping arrangements to your location.
| Specifications | Value |
|---|---|
| No. | 1074852 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 13500 |
| Bucket capacity (m³) | 0.23-0.71 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2100 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins B3.9-C |
| Rated power (kw/rpm) | 84/2100 |
| Total displacement (L) | 3900 |
| Cooling mode | water-cooling |
| Forward speed (Km/h) | 7.9-30 |
| Rotation speed (rpm) | 14.5 |
| Climbing ability (%) | 33 ° |
| Bucket digging force (kN) | 83.4 |
| Rod digging force (kN) | 71.6 |
| Maximum flow of main pump (l/min) | 2 x 130 |
| Main pump type | 2× axial variable piston pump |
| Fuel Tank (L) | 270 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 15.3 |
| Total transport length (mm) | 7800 |
| Total transport width (mm) | 2500 |
| Total transport height (mm) | 3500 |
| Full cab height (mm) | 3140 |
| Counterweight ground clearance (mm) | 1240 |
| Wheelbase (mm) | 2600 |
| Wheel base (mm) | 1945 |
| Minimum ground clearance (mm) | 435 |
| Back end turning radius (mm) | 2310 |
| Maximum digging radius (mm) | 7920 |
| Maximum excavation radius (mm) | 7700 |
| Maximum digging depth (mm) | 4820 |
| Maximum excavation height (mm) | 8490 |
| Maximum unloading height (mm) | 6060 |
| Maximum vertical digging depth (mm) | 4230 |
| Maximum digging depth (mm) | 4570 |
| Minimum turning radius (mm) | 2680 |
| Dodging plate width × height (mm) | 2490 x 559 |
