Product Description
Engineered for demanding excavation operations, this 22-ton class machine delivers robust performance through precision hydraulics and proven powertrain technology. At its core, a 114kW engine operating at 2000 rpm provides consistent power delivery, while the dual main pump system flows 2 x 228.2 l/min to ensure responsive control across all functions. The 107 x 124mm cylinder configuration optimizes fuel efficiency without compromising operational capability.
Hydraulic architecture demonstrates Hyundai's commitment to engineering excellence. Boom cylinders feature dual 120mm diameter units with 1290mm stroke, delivering 21kN maximum tractive force for challenging ground conditions. The bucket rod cylinder (140 x 1510mm) and bucket cylinder (120 x 1055mm) provide exceptional breakout force and precise material handling. With a 35° climbing ability and dual-speed travel system (5.7/3.6 km/h), this 220LC model maintains productivity across varied terrain.
Key specifications include:
- Operating weight: 22,400 kg with optimal stability
- Joint venture/import manufacturing standards
- Backhoe configuration for versatile applications
- Available in 河北 region
| Specifications | Value |
|---|---|
| No. | 1006173 |
| Tonnage (tons) | 22 |
| Working weight (kg) | 22400 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Rated power (kw/rpm) | 114/2000 |
| Cylinder diameter × stroke (mm) | 107 x 124 |
| Climbing ability (%) | 35° (70%) |
| Maximum tractive force (kN) | 21 |
| Travel speed (km/h) | 5.7/3.6 High/Low |
| Maximum flow of main pump (l/min) | 2 x 228.2 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1055 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1510 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 1290 |
