Product Description
Built to endure the toughest conditions, this 2016 Hyundai HX305L excavator represents proven engineering excellence with years of reliable performance behind it. Operating under China's National IV emission standards, this machine has demonstrated its capability as a true workhorse in河北's demanding construction and excavation environments. With over seven years of field-tested operation, its durability speaks volumes about Hyundai's commitment to quality manufacturing and robust design.
- Proven track record since 2016 with consistent performance
- National IV compliant engine meeting environmental standards
- Heavy-duty construction designed for long-term reliability
- Field-tested in河北's diverse working conditions
- Established maintenance history demonstrating longevity
For contractors seeking dependable equipment with a documented service life, this HX305L delivers the reliability your operations demand. Its sustained performance over multiple seasons confirms the solid engineering that defines Hyundai's excavator lineup. Ready for continued productive service in your fleet.
| Specifications | Value |
|---|---|
| No. | 1009045 |
| Tonnage (tons) | 31 |
| Working weight (kg) | 31700 |
| Bucket capacity (m³) | 1.44/1.63 |
| Boom length (mm) | 6250 |
| Rod length (mm) | 3050/2850 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins B7 |
| Rated power (kw/rpm) | 173/2000 |
| Cylinder diameter × stroke (mm) | 107*124 |
| Maximum torque (N.m) | 949/1200 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Rotation speed (rpm) | 10.7 |
| Travel speed (km/h) | 5.6/3.2 |
| Turning torque (Nm) | 93.7k |
| Maximum flow of main pump (l/min) | 2*285 |
| Fuel Tank (L) | 460 |
| Hydraulic Tank (L) | 200 |
| Engine Oil changes (L) | 34 |
| Coolant (L) | 41 |
| Hydraulic System (L) | 360 |
| Urea Tank (L) | 70 |
| Total transport length (mm) | 10600 |
| Total transport width (mm) | 3200 |
| Total transport height (mm) | 3240 |
| Full cab height (mm) | 3130 |
| Counterweight ground clearance (mm) | 1190 |
| Minimum ground clearance (mm) | 500 |
| Minimum turning radius of front working device (mm) | 4280 |
| Back end turning radius (mm) | 3210 |
| Onboard width (mm) | 2980 |
| Total track length (mm) | 4940 |
| Track gauge (mm) | 2600 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4030 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 48 |
| Maximum digging radius (mm) | 10785 |
| Maximum digging depth (mm) | 7305 |
| Maximum excavation height (mm) | 10115 |
| Maximum unloading height (mm) | 7175 |
| Maximum vertical digging depth (mm) | 5065 |
| Maximum excavation radius of stop surface (mm) | 10580 |
