Built for immediate deployment on demanding jobsites, this 2020 Hyundai HX60 compact excavator delivers 6-ton performance where precision matters most. Powered by a reliable Yanmar 4TNV94L engine generating 36.2 kW at 2200 rpm, this machine tackles digging, grading, and demolition tasks with consistent hydraulic power. The 0.21 m³ bucket capacity and 46.7 kN digging force cut through tough materials efficiently, while the 3760 mm maximum digging depth and 6127 mm reach provide exceptional working range for trenching and foundation work.
- Variable piston pump system with 138 l/min flow for responsive control
- Standard hydraulic crushing pipeline for attachment versatility
- Compact footprint: 5900 mm length, 1920 mm width for confined spaces
- 70% climbing ability handles steep grades confidently
- Two-speed travel (4.6/2.4 km/h) optimizes productivity and maneuverability
- Water-cooled 4-cylinder engine ensures reliable operation in Hunan's climate
Currently located in Hunan, this joint venture-manufactured excavator arrives ready for site work with proven components and straightforward operation. No break-in period required—mount the operator, fire the engine, and star
| Specifications | Value |
|---|---|
| No. | 998020 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5720 |
| Bucket capacity (m³) | 0.21 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L-ZXSHYB(XSNSRE) |
| Rated power (kw/rpm) | 36.2/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 94 x 110 |
| Maximum torque (N.m) | 201.1/1400 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.053 |
| Working form | 4 stroke, direct injection engine |
| Rotation speed (rpm) | 10.88 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 46.7 |
| Rod digging force (kN) | 27.5 |
| Travel speed (km/h) | 4.6 / 2.4 |
| Rotary hydraulic motor type | Axial piston motor with automatic braking |
| Type of walking hydraulic motor | Two-speed axial plunger motor with brake valve and parking brake |
| Maximum flow of main pump (l/min) | 138 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Variable piston pump |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-80 * 50 * 660 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-85 * 55 * 850 |
| Boom cylinders - Number × diameter × stroke (mm) | 1-105 * 60 * 715 |
| Fuel Tank (L) | 118.5 |
| Hydraulic Tank (L) | 70 |
| Engine Oil changes (L) | 11.6 |
| Coolant (L) | 10 |
| Hydraulic System (L) | 120 |
| Total transport length (mm) | 5900 |
| Total transport width (mm) | 1920 |
| Total transport height (mm) | 2550 |
| Full cab height (mm) | 1860 |
| Minimum turning radius of front working device (mm) | 2350 |
| Back end turning radius (mm) | 1650 |
| Track ground length (mm) | 1990 |
| Number of sprockets (single side) (each) | 1 |
| Number of wheels (single side) (each) | 5 |
| Number of track plates (single side) (PCS) | 40 |
| Maximum digging radius (mm) | 6127 |
| Maximum digging depth (mm) | 3760 |
| Maximum excavation height (mm) | 5753 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 2915 |
| Maximum excavation radius of stop surface (mm) | 5990 |
